Ginga Leopard - IMO 9425992

Westerschelde 18 February 2020

Name

GINGA LEOPARD

Type

Oil/ Molasses/ Chemical tanker

IMO-number

9425992

Call sign

H9MA

Flag

Republic of Panama

Port of registry

Panama City

GRT

16.222 t

DWT

Summer: 25.982 t

NRT

7.983 t

Length

159,98 m overall

Breadth

26,80 m moulded

Draught

Summer: 10,08 m

Keel to mast end

40,66 m

Moulded L x B x D

154,00 x 26,80 x 14,20 m

Registered L x B x D

154,31 x 26,80 x 14,20 m

Freeboard

Summer: 4.165 mm

Depth

14,20 m moulded

Speed

Service: 15,2 knots

Max: 18,8 knots

Built

2008

Keel laid

29/02/2008

Launch date

04/07/2008

Date of completion

13/11/2008

Builder

Shin Kurushima Dockyard Co., Ltd.

Akitsu

Japan

Yard number

5471

Hull material

Steel

Hull type

Double hull

Main engine

1x Mitsubishi/Kobe 6UEC52LA - 2 stroke single acting 6 cylinder 520 x 1.600 mm combustion engine 7.080 kW / 9.626 hp at 133,0 rpm

Manufacturer: Kobe Diesel Co., Ltd.

Propeller shaft

1x Oil lubrication shaft with monitoring device

Diameter: 445 mm

Propellers

1x Fixed pitch propeller

Boilers

1x Auxiliary vertical boiler - 0,98 MPa

Evaporation: 16,02 t/h

Manufacturer: Tortoise Engineering Co., Ltd.

Generators

3x Main diesel generatorsets each 620 kW

Bow thruster

1x 588 kW

Cargo tank capacity

Liquid: 29.575 m³

Number of tanks

26

Tank capacities

Fuel oil: 1.333 m³

Fresh water: 531 m³

Number of pumps

16x Cargo pumps each 330 m³/h

10x Cargo pumps each 200 m³/h

Commercial manager

MOL Chemical Tankers Pte Ltd.

15-01, UIC Building, 5, Shenton Way

Singapore

ISM manager

TM Shipmanagement Co Ltd.

8th Floor, Korea Seafarers' Center Building

66, Chungjang-daero 9beon-gil, Jung-gu, Busan

South Korea

Registered owner

MOL Chemical Tankers Pte Ltd.

15-01, UIC Building, 5, Shenton Way

Singapore

Latest data adjustment

18 October 2021
