| Westerschelde 10 May 2020 |
|
Name |
NAMRATA |
|
Previous names |
07/2008 - 09/2017 Ratna Namrata |
|
Type |
Crude oil tanker |
|
IMO-number |
9401154 |
|
Call sign |
9HA4646 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
India, Kolkata - Call sign: AUPZ |
|
GT |
57.144 t registered Suez: 59.018,12 t |
|
DWT |
Summer: 105.726 t |
|
NT |
32.440 t registered Suez: 54.248,89 t |
|
Light ship |
17.165,6 t |
|
Displacement |
11.1053 t |
|
Length |
243,97 m overall 234,00 m between perpendiculars |
|
Breadth |
42,03 m moulded |
|
Draught |
13,62 m |
|
Radar mast above keel |
50,01 m |
|
Fore mast above keel |
34,32 m |
|
Depth |
21,00 m moulded |
|
Speed |
15,4 knots |
|
Built |
2008 |
|
Keel laid |
13/02/2008 |
|
Launch date |
03/05/2008 |
|
Date of completion |
18/07/2008 |
|
Builder |
Hyundai Heavy Industries & Engineering Division 1000 Bangeojinsunhwan-Doro, Dong-Gu Ulsan South Korea |
|
Yard number |
1947 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Non tight: 1 Water tight: 1 Oil tight: 9 |
|
Main engine |
1x Hyundai/MAN-B&W 6S60MC-C - 2 stroke 6 cylinder 600x 2.400 mm combustion engine 13.560 kW at 105,0 rpm Manufacturer: HHI Engine & Machinery Division |
|
Propellers |
1x Fixed pitch propeller Nickel, Aluminium, Bronze - 4 blades Diameter: 7.200 mm |
|
Boilers |
1x Exhaust gas economizer - 18,0 MPa 2x Auxiliary water tube boiler - 18,0 MPa Manufacturer: Aalborg Industries Ltd. |
|
Generators |
3x HFC7 506-14K main diesel generatorsets each 730 kW Manufacturer: HHI, Electro Electric System |
|
Number of cargo tanks |
14 |
|
Cargo tank capacity |
119.659,6 m³ |
|
Cargo oil pump |
3x Single stage steam turbine drive each 3.000 m³/h Builder: HHI EMD |
|
Water ballast pump |
2x (1 Steam + 1 Electric driven) Type: Single stage steam turbine drive Capacity: 1.500 m³/h Builder: HHI EMD |
|
Cargo oil stripping pump |
1x Steam driven reciprocating Capacity: 300 m³/h Builder: HHI EMD |
|
Cargo oil stripping eductor |
1x Driving liquid from cargo oil pumps Capacity: 400 m³/h Builder: Teamtec |
|
Manifolds |
Manifold centre to bow 121,46 m Manifold centre to stern 122,45 m Manifold centre to accommodation front: 81,16 m |
|
Number of tanks |
Ballast: 14 Fuel oil: 8 Lubricating Oil: 7 Sludge: 4 Fresh water: 3 Chain: 2 Diesel oil: 2 |
|
Tank capacities |
Diesel Oil: 159,70 m³ Freshwater: 373,50 m³ Fuel Oil: 2.910,40 m³ Lube Oil: 169,90 m³ Tank Ballast: 37.807,40 m³ |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 15,0 t 1x Port provision crane - SWL 4,0 t 1x Starboard side provision crane - SWL 2,0 t Manufacture: Oriental Precision & Eng'g Co.,Ltd. 1x Engine room crane - SWL 4,0 t Manufacture: Dong Nam Marine Crane Co.,Ltd. |
|
ISM & commercial manager |
Marine Trust Ltd. Vergoti Square Glyfada, 166 75 Athens Greece |
|
Registered owner |
Gizmo Shipping Ltd. - Malta Care of Marine Trust Ltd. Vergoti Square, Glyfada 166 75 Athens Greece |
|
Latest data adjustment |
12 February 2022 |
