| Westerschelde 20 November 2019 |
|
Name |
CEVDET A |
|
Type |
Oil/Chemical tanker |
|
IMO-number |
9474450 |
|
Call sign |
9HTW9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
7.244 t Suez: 7.702,52 t |
|
DWT |
Summer: 11.161 t Winter: 10.912 t |
|
NT |
3.643 t Suez: 6.228,39 t Panama: 6.138 t |
|
Displacement |
Summer: 15.178 t Winter: 14.929 t |
|
Length |
129,75 m overall 123,40 m between perpendiculars |
|
Breadth |
19,60 m moulded |
|
Draught |
Summer: 8,00 m Winter: 7,83 m |
|
Keel to mast end |
33,80 m |
|
Air draft |
Summer deadweight: 25,80 m Normal ballast: 27,73 m Lightship: 31,50 m |
|
Freeboard |
Summer: 2.410 mm Winter: 2.580 mm |
|
Depth |
10,40 m moulded |
|
Speed |
Laden: 12,5 knots -Economic: 10,0 knots |
|
Built |
2008 |
|
Date of completion |
19/11/2008 |
|
Builder |
Admarine Shipbuilding Trading Inc. Istanbul Turkey |
|
Yard number |
13 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN 6S35MC - 2 stokes single acting 6 cylinders 350 x 1.400 mm combustion engine 4.440 kW / 6.037 hp at 173,0 rpm |
|
Propellers |
1x Controllable pitch propeller - aft at 173,0 rpm |
|
Generators |
3x MAN D2842LE 301 main diesel generatorsets each 620 w at 1.800 rpm |
|
Bow thruster |
1x Schottel STT-170755 - 450 kW / 600 bhp |
|
Number of tanks |
14 + 2 slop tanks |
|
Total tank capacity 98% |
Seg#1: 807,671 m³ (1p/s) Seg#2: 1.102,041 m³ (2p/s) Seg#3: 2.094,195 m³ (3p/s) Seg#4: 2.120,003 m³ (4p/s) Seg#5: 2.118,962 m³ (5p/s) Seg#6: 2.116,213 m³ (6p/s) Seg#7: 1.990,297 m³ (7p/s) Tital: 11.334,30 m³ |
|
Slop tank capacity 98% |
2x 253 m³ |
|
Pumps |
14x Deepwell hydraulic driven cargo pups each 300 m³/h 1x Centrifugal electric driven cargo pump 50 m³/h 1x Portable spare pump 2x Centrifugal ballast pumps each 350 m³/h |
|
Manifolds |
Distance bridge front to centre of manifold: 36,90 m Bow to centre manifold: 68,60 m Stern to centre manifold: 61,10 m Distance between cargo manifold centres: 900 mm Distance ships rail to manifold: 4.160 mm Distance manifold to ships side: 4.500 mm Top of rail to centre of manifold: 4.160 mm Distance main deck to centre of manifold: 2.215 mm Spill tank grating to centre of manifold: 655 mm |
|
Tank capacities |
HFO: 507,24 m³ MGO: 101,16 m³ |
|
Lifting equipment |
1x Crane - SWL 5,0 t 1x Crane - SWL 2,0 t |
|
Commercial manager |
Transteckmarine Buyukdere cad. Cem Plaza, no 23/9, Sisli Istanbul Turkey |
|
ISM Manager |
Chemfleet Orhantepe Mah. Sögüt Sok. No:6 - 34865 Dragos - Kartal Turkey |
|
Registered owner |
Transay Shipping Limited 171 Old Bakery Street Valletta Malta |
|
Renamed |
11/2020 Rubino Italy, Genova - Call sign: ICHR Manager: Finbeta Spa, Savona - Italy Owner: Apuana Shipping Ltd. |
|
Latest data adjustment |
13 April 2022 |
