| Westerschelde 02 November 2019 |
 |
| Westerschelde 02/11/19 |
|
Name |
ATLANTIS ALHAMBRA |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9508110 |
|
Call sign |
9HA2101 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
4.276 t |
|
DWT |
6.435 t |
|
NT |
1.992 t |
|
Length |
109,00 m overall 103,10 m between perpendiculars |
|
Breadth |
16,80 m |
|
Draught |
Summer: 6,65 m |
|
Keel to mast end |
32,90 m |
|
Freeboard |
1.661 mm |
|
Depth |
8,30 m |
|
Speed |
14,5 knots |
|
Built |
2009 |
|
Delivery date |
03/09/2009 |
|
Builder |
Yildirim Gemi Insaa Sanayti A.S. Tuzla Turkey |
|
Yard number |
117 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MaK 8M25C - 4 stroke 8 cylinder 255 x 400 mm combustion engine 2.640 kW / 3.587 hp at 750 rpm Builder: Caterpillar Motoren GmbH & Co. KG, Kiel Germany |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
2x CHO 63,00 m² - 10,0 bar 1x CHR 82,70 m² - 10,0 bar |
|
Generators |
3x Main diesel generatorsets each 462 kVA - 370 kW - 530 hp |
|
Emergency generator |
1x Diesel generatorset174 kVA - 139 kW - 272 hp |
|
Bow thruster |
1x 346 kW |
|
Number of tanks |
10 + 2 slop tanks |
|
Cargo tank capacity |
Liquid: 6.858 m³ |
|
Number of pumps |
10x Cargo pumps each 200 m³/h |
|
Segregation |
12x Segregation with double valves |
|
Tank capacities |
Fuel: 1.474,77 m³ |
|
Cargo gear |
14 |
|
Commercial manager |
Atlantis Tankers Muallim Naci Caddesi No: 47 TR-34347 Ortaköy Beşiktaş / İstanbul Turkey |
|
ISM manager |
Armona Denizcilik AS Muallim Naci Caddesi 47, Ortakoy Mah, Besiktas, 34347 Istanbul Turkey |
|
Registered owner |
Alhambra Shipping Ltd. Care of Armona Denizcilik AS Muallim Naci Caddesi 47, Ortakoy Mah, Besiktas, 34347 Istanbul Turkey |
|
Latest data adjustment |
03 June 2022 |
