Westerschelde 23 April 2017 |
 |
 |
 |
||
| Westerschelde 23/04/17 | Westerschelde 20/04/17 | Westerschelde 20/04/17 | ||
|
Name |
HIGH VOYAGER |
|
Type |
Oil product tanker |
|
IMO-number |
9681845 |
|
Call sign |
D5TO3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
11/2014 - 04/2019 Malta, Valletta - Call sign: 9HA3475 |
|
GT |
29.935 t |
|
DWT |
45.999 t |
|
NT |
12.124 t |
|
Displacement |
56.756 t |
|
Length |
183,00 m overall 174,00 m between perpendiculars |
|
Breadth |
32,20 m moulded |
|
Draught |
Summer: 12,59 m |
|
Keel to mast end |
48,30 m |
|
Freeboard |
6.836 mm |
|
Depth |
19,40 m moulded |
|
Speed |
14,5 knots |
|
Built |
2014 |
|
Keel laid |
10/06/2014 |
|
Delivery date |
10/11/2014 |
|
Builder |
Hyundai Mipo Dockyard Co. Ltd. 100 Bangeojinsunhwan-Doro Dong-Gu Ulsan South Korea |
|
Yard number |
2387 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
12 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W /HHI 6G50ME-B9.3 - 6 cylinder 500 x 2.214 mm combustion engine Mcr 7.180 kW / 9.762 hp at 87,1 rpm Manufacturer: HHI Engine & Machinery Div. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler - 9,0 MPa 1x Composite boiler - 9,0 MPa Manufacturer: Kangrim Heavy Industries Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 800 kW |
|
Number of tanks |
12 + 2 slop tanks |
|
Cargo tank capacity |
54.646,50 m³ |
|
Number of pumps |
12x Cargo pumps each 600 m³/h |
|
Tank capacities |
Lub oil: 131,10 m³ Hydraulic oil: 17,90 m³ Ballast: 22.443,60 m³ Fresh water: 276,40 m³ Fuel oil: 1.445,90 m³ Diesel oil: 263,60 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t 1x Engine room crane - SWL 4,0 t 1x Provision crane port - SWL 2,0 t 1x Provision crane Stbd - SWL 4,0 t |
|
Crew size |
28 |
|
Manager |
D'Amico Societa Di Navigazione Corso d'Italia 35B 00198 Rome RM Italy |
|
Registered owner |
Hashihama Shipping Pte. Ltd. (Foreign Maritime Entity) |
|
Latest data adjustment |
06 December 2022 |
