| Vlissingen (NL) 23 April 2018 |
 |
 |
|
| Vlissingen 23/04/18 | Vlissingen 23/04/18 | |
|
Name |
BUNGA ANGSANA |
|
Type |
Chemical/Oil products tanker |
|
IMO-number |
9399349 |
|
Call sign |
9MLI2 |
|
Flag |
Malaysia |
|
Port of registry |
Port Klang |
|
GT |
25.723 t |
|
DWT |
Summer: 37.985,6 t |
|
NT |
9.363 t |
|
Displacement |
44.343,9 t |
|
Length |
180,00 m overall 171,20 m between perpendiculars |
|
Breadth |
32,03 m moulded |
|
Draught |
Summer: 10,22 m |
|
Keel to mast end |
43,15 m |
|
Freeboard |
6.013 mm |
|
Depth |
16,20 m moulded |
|
Speed |
Service: 15,1 knots |
|
Built |
2010 |
|
Keel laid |
13/11/2009 |
|
Launch date |
16/01/2010 |
|
Date of completion |
15/04/2010 |
|
Builder |
STX Offshore & Shipbuilding Co., Ltd. - Changwon (Jinhae Shipyard) 60, Myeongje-Ro, Jinhae-Gu Chang-Won-Si, Gyeongsangnanm-Do South Korea |
|
Yard number |
S2049 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x STX/MAN-B&W 6S50MC-C - 2 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine Mcr 9.488 kW / 12.900 hp at 127,0 rpm Builder: STX Engine Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 127,0 rpm |
|
Boilers |
1x Auxiliary boiler - 9,0 MPa 1x Exhaust gas economizer - 12,0 MPa Manufacturer: Kangrim Heavy Industries Co., Ltd. |
|
Generators |
3x Man-B&W 6L23/30H - 4 stroke 6 cylinder 225 x 300 diesel engines each Mcr 960 kW connected with generators each 910 kW - 450 Volt 60 Hz |
|
Number of tanks |
18 + 2 slop tanks |
|
Cargo tank capacity 98% |
43.055 m³ |
|
Slop tank capacity |
1.178 m³ |
|
Number of pumps |
18x Cargo pumps each 550 m³ |
|
Tank capacities |
Fuel oil: 1.784,60 m³ Diesel oil: 151,90 m³ Ballast: 20.836,70 m³ Hydraulic oil: 21,30 m³ Fresh water: 977,70 m³ Lub oil: 107,80 m³ |
|
Lifting equipment |
1x Engine room crane - SWL 2,5 t 1x Hose handling crane-midship - 10,0 t 1x Provisions crane port side- SWL 2,5 t 1x Provisions crane starboard- SWL 2,5 t |
|
Crew size |
23 |
|
Manager |
AET Product Tankers Sdn Bhd Level 30, Menara Dayabumi, Jalan Sultan Hishamuddin 50050 Kuala Lumpur Malaysia |
|
Registered owner |
AET Product Tankers Sdn Bhd |
|
Previous owners |
MISC Berhad - Malaysia |
|
Renamed |
2019 Henriette Maersk Republic of Singapore, Singapore City - Call sign: 9V3479 Owner: Maersk Tankers Singapore Pte - Republic of Singapore Operator: Synergy Denmark A/S |
|
Latest data adjustment |
07 March 2023 |
