| Westerschelde 21 April 2017 |
 |
|
| Westerschelde 21/04/17 | |
|
Name |
ALAND |
|
Previous names |
2013 - 2017 Anzer |
|
Type |
Oil Tanker/ Chemical tanker |
|
IMO-number |
9487380 |
|
Call sign |
9HA4298 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2013 - 2017 Turkey, Istanbul - call sign: TCVR5 |
|
GT |
3.308 t registered |
|
DWT |
Summer: 4.994,7 t |
|
NT |
1.503 t registered |
|
Displacement |
7.110,5 t |
|
Length |
99,84 m overall 94,76 m between perpendiculars |
|
Breadth |
15,60 m moulded |
|
Draught |
6,10 m |
|
Freeboard |
1.511 mm |
|
Depth |
7,60 m moulded |
|
Speed |
12,5 knots |
|
Built |
2013 |
|
Keel laid |
28/12/2007 |
|
Launch date |
31/10/2012 |
|
Delivery date |
19/04/2013 |
|
Builder |
Yardimci Gemi Insaat A.S. Aydintepe Mah. Tersaneler Bolgesi Billur Sok. No:7 Tuzla, Istanbul Turkey |
|
Yard number |
77 |
|
Hull material |
Ordinary strength steel High strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
23 |
|
Main engine |
2x Wärtsilä 6L20 - 4 stroke 6 cylinder 200 x 280 mm combustion engines each Mcr 1.080 kW at 1.000 rpm Total Mcr 2.160 kW / 2.934 kW Built: 2013 Builder: Wärtsilä Finland Ltd., Vaasa - Finland |
|
Gearbox |
2x Wärtsilä SCV 46-P35 - reduction 4,78:1 |
|
Propellers |
2x Controllable pitch propellers - aft at 200 rpm |
|
Boilers |
1x CHR BO 974819-X1 - 65,00 m² / 10,0 bar 1x CHR BO 974819-X2 - 65,00 m² / 10,0 bar 2x CHO BO 974818 - 50,00 m² / 10,0 bar |
|
Shaft generator |
2x Generator each 838 kVA - 670 kW Manufacturer: Marelli Motori SpA |
|
Generators |
1x Diesel generatorset 313 kVA - 250 kW - 340 hp Manufacturer: Leroy Somer |
|
Number of cargo tanks |
10 |
|
Cargo tank capacity 100% |
Liquid: 5.462,23 m³ |
|
Number of slop tanks |
2 |
|
Number of tanks |
Ballast: 11 Fuel oil: 7 Fresh water: 5 Diesel oil: 5 Waste water: 4 Lubricating oil: 3 Chain: 2 Hydraulic oil: 2 Thermal oil: 2 Sludge: 2 Chemical: 1 |
|
Tank capacity |
Diesel oil: 55,52 m³ Freshwater: 209,55 m³ Fuel oil: 260,62 m³ Hydraulic oil: 4,71 m³ Lube oil: 12,84 m³ Tank Ballast: 1.750,29 m³ |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 5,0 t 1x Provision & rescue boat crane - SWL 20, t Manufacture: Gurdesan Gemi Mak. San |
|
Manager |
Besiktas Likid Tasimacilik Denizcilik Ticaret AS Memorial Center A Blok Kat:15 Okmeydanı 34385 Istanbul Turkey |
|
Registered owner |
Aland Tanker Co., Ltd. - Vallatta - Malta Care of Besiktas Likid Tasimacilik Denizcilik Ticaret AS Istanbul Turkey |
|
Previous names & owners |
2013 - 2017 Anzer - Yardimci Gemi Insaat A.S., Istanbul - Turkey |
|
Renamed |
2017 MT Alang Malta, Valletta - call sign: 9HA4298 |
|
Latest data adjustment |
04 April 2023 |
