| Westerschelde 14 September 2015 |
 |
|
| Westerschelde 14/09/15 | |
|
Name |
MTM SANTOS |
|
Type |
Chemical & oil tanker |
|
IMO-number |
9712606 |
|
Call sign |
9V2996 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GRT |
13.122 t Suez: 13.703,68 t |
|
DWT |
Summer: 22.396 t Winter: 21.728 t |
|
NRT |
6.544 t Suez: 11.149,03 t Panama: 11.200 t |
|
Displacement |
Summer: 28.565 t Winter: 27.897 t |
|
Light ship |
6.196 t |
|
Length |
149,93 m overall |
|
Breadth |
24,60 m moulded |
|
Draught |
Summer: 10,17 m Winter: 9.95 m |
|
Moulded L x B x D |
143,00 x 24,60 x 13,20 m |
|
Registered L x B x D |
143,02 x 24,60 x 13,20 m |
|
Keel to mast end |
39,76 m |
|
Air draft |
Lightship: 34,76 m Normal ballast: 33,18 m At loaded summer deadweight: 29,61 m |
|
Freeboard |
Summer: 3.069 mm Winter: 3.280 mm |
|
Depth |
13,20 m moulded |
|
Speed |
Max: 15,3 knots |
|
Built |
2015 |
|
Keel laid |
29/09/2014 |
|
Launch date |
13/01/2015 |
|
Date of completion |
21/05/2015 |
|
Builder |
Shin Kurushima Dockyard Co., Ltd. Imabari Japan |
|
Yard number |
5823 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mitsubishi 6UEC45LSE - 2 stroke single acting 6 cylinder 450 x 1.840 mm combustion engine 4.860 kW / 6.608 hp at 101,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 415 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,98 MPa Evaporation: 15,60 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x main diesel generatorsets each 660 kW |
|
Number of tanks |
18 + 2 slop tanks |
|
Cargo tank capacity 98% |
Seg#1: 873,24 m³ (1P) Seg#2: 864,29 m³ (1S) Seg#3: 1.185,36 m³ (2P) Seg#4: 1.185,57 m³ (2S) Seg#5: 1.342,71 m³ (3P) Seg#6: 1.342,50 m³ (3S) Seg#7: 1.376,03 m³ (4P) Seg#8: 1.376,25 m³ (4S) Seg#9: 631,39 m³ (5P) Seg#10: 642,46 m³ (5S) Seg#11: 1.376,28 m³ (6P) Seg#12: 1.376,06 m³ (6S) Seg#13: 1.377,41 m³ (7P) Seg#14: 1.377,63 m³ (7S) Seg#15: 1.352,20 m³ (8P Seg#16: 1.351,99 m³ (8S) Seg#17: 1.181,91 m³ (9P) Seg#18: 1.183,08 m³ (9S) Slop: 422,62 m³ (S-Slop) Slop: 415,07 m³ (P-Slop) Liquid: 22.134,24 m³ |
|
Slop tank capacity 98% |
837,79 m³ |
|
Number of pumps |
20x Centrifugal cargo pumps each 200 m³/h 2x Centrifugal ballast pumps each 350 m³/h |
|
Manifolds |
Bow to centre manifold: 75,39 m Stern to centre manifold: 74,55 m Distance bridge front to centre of manifold: 45,58 m Distance between cargo manifold centres: 500 mm Distance ships rail to manifold: 3.399 mm Distance manifold to ships side: 3.500 m Top of rail to centre of manifold: 1.961 mm Distance main deck to centre of manifold: 3.050 mm |
|
Tank capacities |
HFO: 998,92 m³ Diesel oil: 120,98 m³ Fresh water: 409 m² |
|
Lifting equipment |
2x Crane - SWL 10,0 t Maximum outreach: 3,70 m |
|
Commercial manager |
MT Maritime Management USA LLC 2960, Post Road Southport CT 06890-1268 USA |
|
ISM manager |
MTM Ship Management Pte Ltd. 13-01, 78, Shenton Way Singapore 079120 Republic of Singapore |
|
Registered owner |
Golden Helm Shipping Co., SA Omega Building, Samuel Lewis Avenue, And 53rd Street Panama City Republic of Panama |
|
Disponent owner |
MTM Trading LLC Trust Company Complex, Ajeltake Island, Ajeltake Road Majuro MH 96960 Marshall Islands |
|
Latest data adjustment |
13 June 2024 |
