Westerschelde 23 December 2016 |
 |
 |
 |
 |
 |
||||
| Westerschelde 23/12/16 | Vlissingen 27/10/12 | Westerschelde 30/1/17 | Westerschelde 03/02/20 | Westerschelde 03/02/20 | ||||
|
Name |
BRO AGNES |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9348302 |
|
Call sign |
9V3608 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
03/2008 - 09/2015 The Netherlands, Delfzijl- Call sign: PHNN |
|
GT |
12.162 t Suez: 12.826,29 t |
|
DWT |
16.796 t |
|
NT |
5.491 t Suez: 10.205,7 t Panama: 10.204 t |
|
Displacement |
22.612,40 t |
|
Length |
144,05 m overall 133,80 m between perpendiculars |
|
Breadth |
23,00 m extreme |
|
Draught |
Summer: 9,00 m |
|
Keel to mast end |
43,70 m |
|
Freeboard |
3.411 mm |
|
Depth |
12,43 m |
|
Speed |
Service: 14,0 knots Max: 16,4 knots |
|
Built |
2008 |
|
Keel laid |
10/12/2005 |
|
Launch date |
11/08/2007 |
|
Date of completion |
10/03/2008 |
|
Builder |
Turkter Tersane ve Deniz Isletmeciligi AS Tuzla - Istanbul Turkey |
|
Yard number |
53 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 6L48/60B - 4 stroke single acting 6 cylinder 480 x 600 mm combustion engine 6.120 kW / 8.321 hp at 500 rpm Builder: MAN-B&W Diesel AG, Augsburg - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, vertical shell type WT 10000 - 9,0 MPa 1x Auxiliary boiler, composite NG - CB 1500 - 9,0 MPa Builder: Garioni Naval Spa |
|
Shaft generator |
1x 1.500 kW |
|
Generators |
3x Caterpillar 3508B - 4 stroke 8 cylinder 170 x 190 mm diesel engine each Mcr 746 kW connected with Leroy Somer LSAM 501 M7 generators each 700 kW Builder: Caterpillar Inc. |
|
Emergency generator |
1x MAN D2866 TE diesel generatorset Builder: MAN Truck & Bus AG - GE Motoren, Nürnberg - Germany |
|
Thrusters |
1x Tunnel thruster 789 kW / 1.073 bhp, forward |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Total cargo capacity |
19.560,05 m³ excl. slops |
|
Slop tanks total cap |
275,74 m³ |
|
Number of pumps |
12x cargo pumps each 385 m³/h |
|
Coating |
Epoxy |
|
Tank capacities |
Water ballast: 7.715,9 m³ Fuel oil: 617,3 m³ Diesel oil: 105,0 m³ Lub oil: 81,0 m³ Hydraulic oil: 18,9 m³ Fresh water: 510,4 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Lifting equipment |
1x Cargo hose handling crane - SWL 10,0 t 1x Engine room crane - SWL 1,0 t 1x Provision crane - SWL 3,0 t |
|
Crew size |
17 |
|
Commercial manager |
Maersk Tankers Singapore Pte. Ltd. 15-01, Robinson Point, 39, Robinson Road Singapore 068911 Republic of Singapore |
|
ISM manager |
Maersk Tankers A/S Holmbladsgade 133 2300 Copenhagen, DK Denmark |
|
Previous managers |
03/2008 - 02/2010 Marin Ship Management B.V., Farmsum - The Netherlands 02/2010 - 09/2015 Broström Tankers Ltd., Gothenburg, Sweden |
|
Operator |
Synergy Denmark A/S |
|
Registered owner |
Maersk Tankers Singapore Pte. Ltd. 15-01, Robinson Point, 39, Robinson Road Singapore 068911 republic of Singapore |
|
Previous owners |
03/2008 - 02/2010 Bro A B.V., Delfzijl - The Netherlands |
|
Latest data adjustment |
05 September 2022 |
