Westerschelde 23 December 2017 |
 |
 |
 |
 |
|||
| Westerschelde 23/12/17 | Westerschelde 23/12/17 | Westerschelde 01/02/12 | Westerschelde 29/08/20 | |||
|
Name |
CANSU Y |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9502673 |
|
Call sign |
9HVX9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flag |
2009 - 2014 Turkey, Istanbul - Call sign: TCTR7 |
|
GT |
2.607 t |
|
DWT |
Summer 3.356 t Winter: 3.226 t |
|
NT |
1.132 t |
|
Length |
92,86 m overall 86,60 m between perpendiculars |
|
Breadth |
14,10 m |
|
Draught |
Summer: 5,70 m |
|
Keel to mast end |
32,00 m |
|
Air draft |
27,00 m ballast conditions 26,30 m loaded conditions |
|
Freeboard |
1.511 mm |
|
Speed |
13,5 knots Service: 10,5 knots |
|
Built |
2009 |
|
Date of completion |
26/05/2009 |
|
Builder |
Dearsan Gemi Insaat San. A.S. Istanbul Turkey |
|
Yard number |
51 |
|
Hull material |
Steel |
|
Hull type |
Double side |
|
Main engine |
MAN-B&W 6L27/38 - 4 stroke 6 cylinder 270 x 380 mm combustion engine 2.040 kW / 2.772 hp at 800 rpm Builder:MAN Diesel A/S, Frederikshavn - Denmark |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
2x CHO S-MAN 35,00 m² - 10,0 bar 1x CHR S-MAN 43,00 m² -10,0 bar |
|
Shaft generator |
1x AVK-Type DSU 62L2-4 - 813 kVA / 50 Hz |
|
Generators |
3x MAN diesel engines connected with 3 Lindeberg generators each 400 kVA - 320 kW - 469 hp |
|
Emergency generator |
1x Diesel generatorset 166 kVA - 133 kW - 181 hp |
|
Bow thruster |
1x 240 kW |
|
Number of cargo tanks |
10 |
|
Cargo capacity 98% |
4.081,70 m³ |
|
Slop tank 98% |
114,42 m³ |
|
Segregations |
5 grades with separate lines and pumps 11 grades by double valves but sharing 6 lines |
|
Number of pumps |
10x Cargo pumps each 150 m³/h 1x Cargo pump 100 m³/h |
|
Loading rate |
400 m³/h |
|
Discharging rate |
150 m³/h x 4 |
|
Tank capacities |
Fuel oil: 212,29 m³ / 182 t Diesel oil: 25 t Water ballast: 1.432 t |
|
Manifolds |
Manifold to main deck: 214 mm Manifold to platform: 90 mm Manifold to stern: 51,06 m Manifold to bow: 41,80 m Manifold to rail: 247 mm |
|
Heating capacity |
Steam heating, max load/discharge temp 90°C / 80°C |
|
Lifting equipment |
1x Crane - SWL 3,0 t 1x Crane - SWL 2,0 t |
|
Commercial manager |
MOL Nordic Tankers A/S Tuborg Boulevard 15 2900 Hellerup Denmark |
|
ISM manager |
Chemfleet Shipping Sogut Sokak 6, Orhantepe Mah, Kartal 34865 Istanbul Turkey |
|
Registered owner |
LZ Shipping Limited Care of MOL Nordic Tankers A/S Tuborg Boulevard 15 2900 Hellerup Denmark |
|
Last data adjustment |
19 November 2021 |
