| Westerschelde 20 July 2018 |
 |
 |
 |
 |
 |
||||
| Westerschelde 18/11/17 | Antwerpen 06/04/10 | Antwerpen 06/04/10 | Westerschelde 12/05/18 | Westerschelde 18/04/17 | ||||
|
Name |
CHANTACO |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9333802 |
|
Call sign |
9HA5421 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2010 - 2022 France, Marseille - Call sign: FMLM |
|
GT |
11.793 t |
|
DWT |
Summer: 18.734 t Winter: 18.168 t |
|
NT |
5.692 t |
|
Light weight |
6.208 t |
|
Length |
143,29 m overall 134,80 m between perpendiculars |
|
Breadth |
23,35 m moulded |
|
Draught |
Summer: 8,89 m Winter: 8,715 m |
|
Keel to mast end |
40,50 m |
|
Air draft |
Summer: 32,50 m ballast: 35,65 m |
|
Freeboard |
2.913 mm |
|
Depth |
11,80 m moulded |
|
Speed |
Max: 15,0 knots Service: 12,0 knots |
|
Built |
2007 |
|
Date of completion |
14/12/2007 |
|
Builder |
RMK Marine Gemi Yapim San. Ve Deniz Tas. Islt. A.S. (Shipyard) Istanbul Turkey |
|
Yard number |
65 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
2x Wärtsilä 8L32 - 4 stroke 8 cylinder 320 x 400 mm combustion engines each 4.000 kW at 750 rpm Total 8.000 kW / 10.870 hp |
|
Propelling system |
2x Controllable pitch propeller - 4 blades |
|
Boilers |
2x CHO 109,00 m² - 10,0 bar 2x CHR 45,00 m² - 10,0 bar |
|
Shaft generator |
2x 2.300 kW |
|
Generators |
2x Diesel generatorsets each 500 kVA - 400 kW - 543 hp |
|
Bow thruster |
1x 900 kW |
|
Cargo tanks |
12x Main tanks + 2 slop tanks |
|
Cargo capacity 98% |
Tank 1 P&S: 3.033,0 m³ Tank 2 P&S: 3.617,0 m³ Tank 3 P&S: 3.024,0 m³ Tank 4 P&S: 3.337,0 m³ Tank 5 P&S :3.336,0 m³ Tank 6 P&S: 2.507,0 m³ Slop tank: 368,1 m³ Total at 98%: 18.854 m³ |
|
Number of pumps |
12x Deepwell Framo cargo pumps each 335 m³/h |
|
Tank capacities |
Fuel oil: 380 m³ Fresh water: 100 m³ |
|
Manager |
Sea-tankers Shipping SAS 7 rue du Golf - Parc Innolin 33700 Merignac France |
|
Registered owner |
Valloeby Chantaco Ltd. Care of ST Management SAS (SAAM) 7, rue du Golf 33700 Merignac France |
|
Renamed |
2023 Algotitan Canada, Halifax - Call sign: VCBA Owner: Algoma Tankers Limited |
|
Latest data adjustment |
16 March 2023 |
