| Westerschelde 28 January 2012 |
 |
 |
 |
||
| Antwerpen 01/08/11 | Antwerpen 01/08/11 | Vlissingen 18/12/11 | ||
|
Name |
CLIPPER SOLA |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9375989 |
|
Call sign |
LAIS6 |
|
Flag |
Norway |
|
Port of registry |
Haugesund |
|
GT |
2.613 t |
|
DWT |
4.054 t |
|
NT |
1.237 t |
|
Length |
89,00 m overall 84,90 m between perpendiculars |
|
Breadth |
13,32 m moulded 13,40 m extreme |
|
Draught |
5,65 m |
|
Depth to main deck |
7,70 m |
|
Speed |
13,1 knots |
|
Built |
2008 |
|
Keel laid |
19.03.2007 |
|
Launch date |
16.07.2008 |
|
Date of completion |
17.09.2008 |
|
Builder |
Volharding Shipyards Newbuilding BV (De Hoop Foxhol) Lange Lijnbaan 1 |
|
Yard number |
631 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MaK 6M25 - 1.980 kW / 2.655 hp at 750 rpm Builder: Caterpillar Motoren GmbH & Co KG, Kiel - Germany |
|
Propeller |
1x Controllable pitch CP75-4 Builder: Scana Volda |
|
Boiler oil fired |
Heatmaster - 1.600 kW |
|
Generators |
2x MAN D2876LE301 main diesel generatorsets each 390 kW at 1.800 rpm Builder: MAN Truck & Bus AG - GE Motoren-Nürnberg |
|
Emergency generator |
1x Cummins 6BT 5,9-series diesel generatorset 107 kW at 1.800 rpm |
|
Bow thruster |
1x Verhaar Omega 3100/120 |
|
Cargo tanks |
10x Duplex 316L Stainless Steel |
|
Cargo capacity |
100%: 4.700 m³ 98%: 4.591 m³ |
|
Segregations |
5 |
|
Cargo pumps |
9x Hamworthy Svanehøy DL100/100 |
|
Cargo / Slop pump |
1x Hamworthy Svanehøy DL80/100 |
|
Ballast capacity |
1.699,18 m³ |
|
Anchor |
Length: 935,00 m Diameter: 36 mm |
|
Manager |
Brødrene Klovning Shipping AS |
|
Operator |
Brodrene Klovning Shipping AS |
|
Owner |
BKR Carriers KS |
