| Westerschelde 15 February 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Antwerpen 02/07/11 | Antwerpen 02/07/11 | Antwerpen 02/07/11 | Westerschelde 03/02/12 | Westerschelde 07/08/16 | Antwerpen 06/07/17 | |||||
 |
 |
 |
||||||||
| Antwerpen 02/07/11 | Westerschelde 23/09/16 | Westerschelde 03/02/12 | ||||||||
|
Name |
GEORG ESSBERGER |
|
Type |
Chemical tanker |
|
IMO-number |
9191175 |
|
Call sign |
CQSW |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
GT |
3.790 t |
|
DWT |
Summer: 5.771 t |
|
NT |
1.684 t |
|
Length |
99,97 m overall 95,33 m registered |
|
Breadth |
16,54 m registered |
|
Draught |
6,787 m |
|
Forecastle |
7,25 m |
|
Poop |
22,75 m |
|
Depth |
8,30 m |
|
Speed |
15,5 knots |
|
Built |
2004 |
|
Keel laid |
31/05/2002 |
|
Launch date |
08/08/2003 |
|
Completion date |
03/03/2004 |
|
Builder |
PO Baltiyskiy Zavod OAO ul. Kosaya Liniya 16 199106 St. Petersburg Russian Federation |
|
Yard number |
05202 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
11 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6L42MC - 2 stroke 6 cylinder 420 x 1.360 mm combustion engine 3.838 kW / 5.221 hp at 145,0 rpm Year of manufacture: 2002 Manufacturer: BMZ - Diesel JSC ul. Ulyanova 26 241015 Bryansk Russian Federation |
|
Propeller |
1x Controllable pitch propeller - aft |
|
Boilers |
1x Thermal oil heater, exhaust gas heated - 12,0 bar Heating surface: 133,5 m² Year of manufacture: 2002 Manufacturer: TUBE-TEC Rohrverformungstechnik GmbH 57647 Nistertal Federal Republic of Germany 1x Thermal oil heater, oil fired - 12,0 bar Heating surface: 61,6 m² Year of manufacture: 2002 Manufacturer: Apparate- und Kesselbau AKB GmbH Baiertaler Str. 98 69168 Wiesloch Federal Republic of Germany |
|
Electric installations |
1x Plant 380/220 V - 769 kVA 1x Plant 380/220 V - 769 kVA 1x Plant 380 V - 737 kVA 1x Plant 380 V - 105 kVA |
|
Shaft generator |
1x 737 kVA |
|
Generators |
2x Volvo Penta D30A-MT main diesel generatorsets each 769 kVA |
|
Emergency generator |
1x Cummins 6BT5.9D diesel generatorset 105 kVA |
|
Compressed air receivers |
2x Receivers each 1.250 litres - 30,0 bar 1x Receiver 290 litres - 30,0 bar 2x Receivers each 1.000 litres - 8,0 bar |
|
Bow thruster |
1x Fixed pitch propeller Schottel - 300 kW, forward |
|
Number of cargo tanks |
20 |
|
Cargo tank capacity |
6.035 m³ |
|
Tank capacities |
Ballast water: 2.467 m³ |
|
Anchor equipment |
3x Anchors weight each 2.640 kg Chain length: 467,50 m Diameter: 40 mm |
|
Manager |
John T. Essberger GmbH & Co. KG Palmaille 45 22767 Hamburg Federal Republic of Germany |
|
Operator |
John T. Essberger |
|
Owner |
MTR Mittelmeer Tank Reederei GmbH & Co. KG Palmaille 45 22767 Hamburg Federal Republic of Germany |
|
Latest data adjustment |
29 May 2024 |
