| Westerschelde 13 October 2012 |
|
Name |
NENA K |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9479668 |
|
Call sign |
9HA2352 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
4.242 t |
|
DWT |
Summer: 6.479,9 t |
|
NT |
1.992 t |
|
Length |
109,00 m overall 103,10 m between perpendiculars |
|
Breadth |
16,80 m moulded |
|
Draught |
Summer: 6,65 m |
|
Height from keel to mast |
32,62 m |
|
Air draft |
Ballast: 28,67 m Loaded condition: 25,97 m |
|
Freeboard |
1.661 mm |
|
Depth |
8,30 m moulded |
|
Speed |
14,5 knots |
|
Built |
2009 |
|
Date of completion |
06.05.2009 |
|
Builder |
Desan Tersanesi |
|
Yard number |
20 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MaK 8M25 - 4 stroke 8 cylinder 255 x 400 mm diesel engine - 2.640 kW / 3.587 hp at 750 rpm Builder: Caterpillar Motoren GmbH & Co. KG |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
2x CHO 38,00 m² - 10,0 bar 1x CHR 25,00 m² - 10,0 bar |
|
Shaft generator |
1x 1.060 kVA - 848 kW |
|
Generators |
3x Volvo Penta diesel generatorsets each 625 kVA - 500 kW - 679 hp |
|
Number of cargo tanks |
12 |
|
Number of segregations |
12 |
|
Cargo tank capacity 98% |
6.888,30 m³ |
|
Slop tank capacity |
143,64 m³ |
|
Pumps |
Cargo: 10x Pumps 220 m³/h each 2x Pumps 70 m³/h each Ballast: 2x Pumps 250 m³/h each |
|
Manifolds |
Distance from bow to centre manifold: 48,80 m Distance from stern to centre manifold: 58,60 m Distance between manifolds: 432 mm Distance from ship side to manifold: 4.230 mm |
|
Tank capacities |
Fuel oil: 387,28 m³ Ballast tank capacity: 2.348,70 m³ |
|
Manager |
K Tankering & Shipmanagement |
|
Operator |
K Tankercilik VE Gemi Isletmeciligi A.S. |
|
Owner |
Chemical Tankers Europe Management |
|
Registered owner |
Nena Marine Ltd. |
|
Last update |
12.04.2013 |
