| Westerschelde 10 October 2015 |
 |
 |
 |
 |
|
 |
|||||
| Westertschelde 07/10/15 | Antwerpen 26/05/16 | Westerschelde 22/08/11 | Westerschelde 17/10/14 | Antwerpen 30/01/18 | Westerschelde 30/04/16 | |||||
 |
||||||||||
| Westertschelde 23/04/20 | ||||||||||
|
Name |
PHILIPP ESSBERGER |
|
Type |
Tanker for oil & chemical products |
|
IMO-number |
9191163 |
|
Call sign |
CQSJ |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
GT |
3.785 t |
|
DWT |
5.738 t |
|
NT |
1.684 t |
|
Length |
99,99 m overall 94,84 m between perpendiculars |
|
Breadth |
16,50 m moulded |
|
Draught |
6,78 m |
|
Forecastle |
7,25 m |
|
Poop |
22,75 m |
|
Depth |
8,30 m moulded |
|
Speed |
15,0 knots |
|
Built |
2003 |
|
Keel laid |
24/12/1999 |
|
Launch date |
26/07/2002 |
|
Date of completion |
22/07/2003 |
|
Builder |
Baltiski Zavod OAO ul. Kosaya Liniya 16 199106 St. Petersburg Russian Federation |
|
Yard number |
05201 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double hull |
|
Watertight bulkheads |
11 |
|
Continuous decks |
1 |
|
Main engine |
1x BMZ 6L42MC - 2 stroke single acting 6 cylinder 420 x 1.360 mm combustion engine 3.839 kW at 145,0 rpm Year of manufacture: 2000 Manufacturer: BMZ - Diesel JSC ul. Ulyanova 26 241015 Bryansk Russian Federation |
|
Propeller |
1x Controllable pitch propeller - aft |
|
Boiler |
1x Thermal oil heater, exhaust gas heated - 12,0 bar Heating surface: 133,5 m² Year of manufacture: 2001 Manufacturer: TUBE-TEC Rohrverformungstechnik GmbH 57647 Nistertal Federal Republic of Germany 2x Thermal oil heater, oil fired - 12,0 bar Heating surface: 61,6 m² Year of manufacture: 2001 Manufacturer: Apparate- und Kesselbau AKB GmbH Baiertaler Str. 98 69168 Wiesloch Federal Republic of Germany |
|
Electric installations |
1x Plant 380/220 V - 769 kVA 1x Plant 380/220 V - 769 kVA 1x Plant 380 V - 737 kVA 1x Plant 380 V - 105 kVA |
|
Shaft generator |
1x 737 kVA |
|
Generators |
2x Main diesel generatorsets each 769 kVA |
|
Emergency generator |
1x Diesel generatorset 105 kVA |
|
Compressed air receivers |
2x Receivers each 1.250 litres - 30,0 bar 1x Receiver 290 litres - 30,0 bar 2x Receivers each 1.000 litres - 8,0 bar |
|
Bow thruster |
1x Schottel fixed pitch propeller - 300 kW, forward |
|
Number of cargo tanks |
20 |
|
Cargo tank capacity |
Liquid: 6.042 m³ |
|
Tank capacities |
Water ballast: 2.462 m³ |
|
Anchor equipment |
3x Anchors weight each 2.640 kg Chain length: 467,50 m |
|
Manager |
John T. Essberger GmbH & Co. KG Palmaille 45 22767 Hamburg Federal Republic of Germany |
|
Registered owner |
WTR Weissmeer Tank Reederei GmbH & Co. KG Palmaille 45 22767 Hamburg Federal Republic of Germany |
|
Latest data adjustment |
26 April 2023 |
