| Merksem, Belgium 21 March 2012 |
 |
| Merksem 12/07/12 |
|
Name |
THEION |
|
Previous names |
1940 Karl Staib 1992 Theion |
|
Type |
Inland oil tanker |
|
ENI-number |
02320649 |
|
Previous EU number |
4400880 |
|
Flag |
The Netherlands |
|
Port of registry |
Druten |
|
Tonnage |
809 t |
|
Length |
67,54 m |
|
Breadth |
8,20 m |
|
Draught |
2,59 m |
|
Depth |
2,40 m moulded |
|
Built |
1941 |
|
Launch date |
10.1940 |
|
Builder |
Bayerische Schiffbauges. mbH vorm. A. Schellenberger |
|
Yard number |
718 |
|
Hull material |
Steel |
|
Watertight bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar C18 - 4 stroke 6 cylinder 145 x 183 mm diesel engine - 600 hp / 447 kW at 1.800 rpm Year of manufacture: 2008 Manufacturer: Caterpillar, Inc. |
|
Previous main engine |
1x MAN diesel engine - 525 hp |
|
Propeller |
1x Solid propeller, aft |
|
Electric installations |
1x Plant 380/220 V - 25 kVA 1x Plant 380/220 V - 145 kVA |
|
Generators |
1x Generator - 25 kVA 1x Generator - 145 kVA |
|
Compressed air receivers |
2x Receivers each 400 litres - 30,0 bar 1x Receiver 500 litres - 8,0 bar |
|
Bow thruster |
1x Transverse thruster DAF - 191 kW, forward |
|
Number of tanks |
13 |
|
Operator |
Wijgula BV |
|
Owner |
1992 WIJGULA Wijnhoff & van Gulpen & Larsen B.V. |
|
Previous names & owners |
1941 Karl Staib - Hoechst AG, Frankfurt am Main - Germany |
|
Demolished |
2014 The Netherlands |
