| Antwerpen 30 April 2013 |
 |
 |
|
| Antwerpen 30/04/13 | Vlissingen 22/11/11 | |
|
Name |
TRINE THERESA |
|
Previous names |
2007 launch as: Marsel 11.2007 - 08.2013 Trine Theresa |
|
Type |
Chemical / Oil products tanker |
|
IMO-number |
9388479 |
|
Call sign |
9HFZ9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
5.265 t |
|
DWT |
Summer: 7914,944 t |
|
NT |
2.415 t |
|
Length |
122,66 m over all 115.31 m between perpendiculars |
|
Breadth |
17,20 m |
|
Draught |
6,85 m |
|
Air draft |
30,75 m |
|
Freeboard |
1.952 mm |
|
Speed |
14,0 knots |
|
Built |
2007 |
|
Date of completion |
26.11.2007 |
|
Builder |
Yildirim Gemi Insaa SAN. A.S |
|
Yard number |
109 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mak 8M32C - 4 stroke 8 cylinder 320 x 480 mm diesel engine - 4.000 kW / 5.435 hp at 600 rpm Builder: Caterpillar Mak Motoren GmbH & Co. KG |
|
Propelling system |
1x Screw propeller controllable pitch LB 10.00 |
|
Boilers |
2x CHO 57,00 m² - 13,0 bar |
|
Generators |
3x MAN diesel generatorsets each 750 kVA - 595 kW - 815 hp |
|
Emergency generator |
1x MAN diesel generatorset 110 KW |
|
Bow thruster |
430 kW |
|
Number of tanks |
13 |
|
Segregation |
14 |
|
Cargo capacity 98% |
8.493,12 m³ + 2x 49 m³ in 2 deck slop tanks |
|
Pumps |
12x Deepweel pumps 30 m³/h 1x Deepweel pumps 100 m³/h 10 1x Centrifugal pump 50 m³/h 10 |
|
Loading rate |
360 m³/h per tank - 150 m³/h cargo tk no 1 |
|
Discharging rate |
1.800 m³/h |
|
Heating capacity |
2.000 KW |
|
Tank cleaning system |
26x Scanjed fixed BW machines - 2x 2.000 KW heater |
|
Manifolds |
Manifold to deck: 3.050 mm Manifold to stern: 58,06 m Manifold to bow: 64,60 m Manifold to rail: 2.500 mm |
|
Tank capacities |
Fuel oil: 427 m³ Diesel oil: 79 m³ Ballast water: 3.640 m³ |
|
Lifting equipment |
1x Crane - SWL 3,0 t at 15,00 m |
|
Manager |
Bernhard Schulte Shipmanagement Republic of Singapore |
|
Operator |
Bernhard Schulte Shipmanagement (Singapore) Pte Ltd Republic of Singapore |
|
Owner |
Trine Theresa K/S Denmark |
|
Registered owner |
Trine Theresa Shipping C/O CS Partnere AS |
|
Renamed |
2013 Nordic Trine |
|
Latest data adjustment |
22 May 2014 |
