Gent, Berlgium 10 May 2015 |
 |
| Antwerpen 28/08/13 |
|
Name |
JANA |
|
Location |
Antwerpen 28 August 2013 |
|
Type |
Inland tanker |
|
ENI-number |
02326684 |
|
Call sign |
PD3607 |
|
Flag |
The Netherlands |
|
Port of registry |
Hansweert |
|
Tonnage |
1.319 t |
|
Length |
81,15 m |
|
Breadth |
9,50 m |
|
Draught |
2,80 m |
|
Depth |
4,25 m |
|
Built |
2004 |
|
Builder casco |
Hangzhou Dongfeng Shipbuilding Co., Ltd. |
|
Builder completion |
H & U Technisch Buro |
|
Hull material |
Steel |
|
Main engine |
1x Caterpillar 3508 (B) DI-TA electronic - 746 kW / 1.014 hp at 1.600 rpm |
|
Gearbox |
1x Reintjes WAF 562L - reduction 5,05:1 |
|
Propellers |
1 |
|
Generators |
1x Cummins N14 diesel engine coupled with Stamford HCM 434F generator 406 kVA 1x Cummins 6BT 5.9G6 diesel engine coupled with Stamford UCM 274E generator 112 kVA 1x Cummins 4B 3.9G2 diesel engine coupled with Stamford UCM 224D generator 40 kVA |
|
Bow thruster |
1x Cummins - van Tiem - 300 hp |
|
Pumps |
4x Bornemann type W6.4zk-75 coupled with electro motor each 37 kW |
|
Tank capacity |
1.400 m³ |
|
Owner |
Jana Scheepvaart (Jackie van Campen) |
|
Last data update |
09 January 2014 |
