Westerschelde 05 March 2012 |
 |
 |
 |
 |
|||
| Westerschelde 05/03/12 | Westerschelde 05/03/12 | Westerschelde 23/02/16 | Westerschelde 28/02/16 | |||
|
Name |
CHEM RANGER |
|
Previous names |
2010 - 03.2012 Wilutama |
|
Type |
Oils, chemicals and molasses vessel |
|
IMO-number |
9490296 |
|
Call sign |
V7YC8 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
16.411 t |
|
DWT |
Summer: 26.198 t |
|
NT |
7.610 t |
|
Length |
159,30 m overall |
|
Breadth |
27,00 m |
|
Draught |
Summer: 10,02 m |
|
Moulded L x B x D |
151,50 x 27,10 x 14,20 m |
|
Registered L x B x D |
159,03 x 27,10 x 14,20 m |
|
Freeboard |
4.215 mm |
|
Depth |
14,20 moulded |
|
Speed |
15,0 knots |
|
Built |
2010 |
|
Keel laid |
07.09.2009 |
|
Launch date |
16.12.2009 |
|
Date of completion |
19.11.2010 |
|
Builder |
Shin Kurushima Hiroshima Dockyard Co., Ltd. |
|
Yard number |
5710 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x 2 stroke single acting 6 cylinder 460 x 1.932 diesel engine - 7.450 kW at 126,0 rpm Manufacturer: Makita Corporation, Amagasaki - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 470 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 9,8 bar Evaporation: 18,95 t/h Manufacturer: Aalborg Industries Limited |
|
Generators capacity |
4x 2.315 kVA |
|
Number of tanks |
18 |
|
Liquid tank capacity |
29.735 m³ |
|
Tank capacities |
Fuel oil: 1.289 m³ Fresh water: 543 m³ Water ballast: 10.433 t |
|
Manager |
Interunity Management Corporation S.A. Chalandri GR 152 31 Athens Greece |
|
Operator |
Chembulk Maritime USA, LLC |
|
Registered owner |
Lantern Maritime Shipping Company Greece |
|
Latest data adjustment |
17 March 2016 |
