Westerschelde 14 April 2017 |
 |
 |
|
| Antwerpen 16/04/14 | Antwerpen 16/04/14 | |
|
Name |
COOLWATER |
|
Type |
Chemical / Products tanker |
|
IMO-number |
9377949 |
|
Call sign |
PHMQ |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
3.561 t |
|
DWT |
5.216 t |
|
NT |
1.501 t |
|
Displacement |
Summer: 7.480,38 t |
|
Light ship |
2.300 t |
|
Length |
99,98 m overall 94,12 m between perpendiculars |
|
Breadth |
16,10 m extreme |
|
Draught |
Summer 6,73 m |
|
Keel to masthead |
32,50 m |
|
Foreship to bridge |
78,32 m |
|
Aft Ship to bridge |
21,65 m |
|
Depth |
8,20 m moulded |
|
Speed |
14,5 knots |
|
Built |
2008 |
|
Keel laid |
31/03/2006 |
|
Launch date |
18/08/2007 |
|
Date of completion |
02/04/2008 |
|
Builder casco |
Ereðli Gemi Inþa Sanayi ve Ticaret AÞ, Karadeniz Turkey Yard number: 363 |
|
Builder |
Breko Shipbuilding & Repair Papendrecht The Netherlands Yard number: 575 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6L38A - 4 stroke 6 cylinder 320 x 400 mm combustion engine 3.540 kW / 4.725 hp at 600 rpm Built: 2007 |
|
Gearbox |
1x Gear SCV-95-PDM |
|
Propellers |
1x Controllable pitch propeller - aft at 128 rpm Diameter: 4,36 m |
|
Generators |
3x MAN D2876 LE 301 - 6 cylinder 128 x 166 mm diesel engines each 319 kW at 1.500 rpm connected with Newage Stamford HCM 534 F generators each 462,5 kVA Built: 2007 |
|
Emergency generator |
1x Cummins 6BT 5.9 - 6 cylinder 102 x 120 mm diesel engine 91 kW at 1.500 rpm connected with Newage Stamford UCM 274 E generator 121 kVA Built: 2007 |
|
Bow thruster |
1x Controllable pitch propeller 440 kW / 590 hp |
|
Number of cargo tanks |
12x Marineline coating |
|
Cargo tank capacity |
100%: 5.918,31 m³ 98%: 5.799,99 m³ 95%: 5.622,39 m³ |
|
Slop tank capacity |
95,66 m³ |
|
Number of cargo pumps |
12 |
|
Manifolds |
Foreship to manifold: 42,33 m Aft ship to manifold: 57,65 m Bridge to manifold: 36,00 m Manifold to main rail P&S :2,50 m Manifold to waterline in ballast: 5,30 m Manifold to waterline in loaded condition: 3,95 m Manifold to main deck: 2,45 m Distance bow to mid-point manifold: 43,00 m Distance stern to mid-point manifold: 56,98 m |
|
Lifting equipment |
1x Gürdesan deck crane - SWL 3,0 t at 15,00 m |
|
Manager |
Clearwater Group Ohmweg 11 2952 BD Alblasserdam The Netherlands |
|
Operator |
Clearwater Group |
|
Owner |
Coolwater C.V Oever 3 3161 GR Rhoon The Netherlands |
|
Latest data adjustment |
25 July 2023 |
