Westerschelde 28 May 2014 |
 |
 |
 |
||
| Westerschelde 12/03/15 | Westerschelde 12/03/15 | Antwerpen 26/05/16 | ||
|
Name |
LS EVANNE |
|
Previous names |
2010 - 06/2012 Kormel |
|
Type |
Oil / Chemical tanker |
|
IMO-number |
9519614 |
|
Call sign |
ZDKW3 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
Previous flags |
2010 - 06/2012 Turkey - Call sign: ICYN2 |
|
GT |
4.765 t |
|
DWT |
Summer: 7.003 t |
|
NT |
2.296 t |
|
Length |
119,10 m overall 111,85 m between perpendiculars |
|
Breadth |
16,90 m moulded |
|
Draught |
Summer: 6,29 m 4,22 m ballast |
|
Height from keel to mast |
37,52 m |
|
Air draft |
33,30 m in ballast 30,77 m loaded condition |
|
Freeboard |
1.679 mm |
|
Depth |
8,40 m moulded |
|
Speed |
13,0 knots |
|
Built |
2010 |
|
Date of completion |
02/06/2010 |
|
Builder |
Umo Shipping Industry & Trade Karadeniz Eregli (Zonguldak) Turkey |
|
Yard number |
02 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M32C - 4 stroke single acting 6 cylinder 320 x 480 mm combustion engine 2.999 kW / 4.077 hp at 600 rpm Builder: Caterpillar Motoren GmbH - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 160 rpm |
|
Boilers |
1x CHR Garioni 51,00 m² - 10,0 bar 2x CHO Garioni 50,70 m² - 10,0 bar |
|
Shaft generator |
1x 950 kVA - 760 kW |
|
Generators |
3x MAN main diesel generatorsets each 554 kVA - 443 kW - 602 hp |
|
Emergency generator |
1x MAN diesel generatorset 224 kVA - 179 kW - 243 hp |
|
Bow thruster |
1x Tunnel thruster 350 kW / 450 bhp, forward |
|
Number of cargo tanks |
12 Cargo tanks + 2 Slop tanks |
|
Number of segregations |
12 + 2 Grades cargo, separate Lines / pumps |
|
Total cap. of tanks 98% |
8.067,04 m³ |
|
Clop tank capacity |
180 m³ |
|
Number of pumps |
12x Marflex Deepwell cargo pumps each 200 m³/h 2x Marflex Deepwell cargo pumps each 50 m³/h |
|
Slop pumps |
2x Deepwell Pump Marflex each 50 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 59,00 m Distance from stern to centre manifold: 60,10 m Distance between manifolds: 410 mm Distance from ship side to manifold: 4.450 mm Distance from deck to manifold: 1.720 mm |
|
Tank capacities |
Fuel oil: 489,6 m³ Ballast: 2.995,05 m³ |
|
Lifting equipment |
1x Hose crane located on main deck midship - SWL 5,0 t 1x Crane - SWL 2,0 t for stores and provisions |
|
ISM & commercial manager |
Lauranne Shipping Wervenweg 2 4551 MC Sas Van Gent The Netherlands |
|
Registered owner |
Evanne Shipping B.V. Care of Lauranne Shipping BV Wervenweg 1 4551 MC Sas van Gent The Netherlands |
|
Renamed |
04/2022 ATA Ocean Malta, Valletta - Call sign: 9HA5604 Owner: Anka Shipping Inc. |
|
Latest data adjustment |
04 June 2022 |
