Name |
NORDIC MARI |
|
Previous names |
2010 - 05/06/2014 Clipper Mari |
|
Type |
Oil Tanker/Chemical tanker |
|
IMO-number |
9422677 |
|
Call sign |
OYDF2 |
|
Flag |
Denmark |
|
Port of registry |
Hellerup |
|
Previous flag |
2010 - 2016 Bahamas, Nassau - Call sign: C6YC7 2016 - 2018 Malta, Valletta - Call sign: 9HA4170 |
|
GT |
11.792 t registered |
|
DWT |
19.355,11 t |
|
NT |
6.160 t registered |
|
Length |
146,60 m overall 138,00 m between perpendiculars |
|
Breadth |
23,70 m moulded |
|
Draught |
9,62 m |
|
Keel to mast end |
37,90 m |
|
Freeboard |
3.414 mm |
|
Depth |
13,00 m moulded |
|
Speed |
14,4 knots |
|
Built |
2010 |
|
Keel laid |
27/04/2009 |
|
Launch date |
08/08/2009 |
|
Date of completion |
12/01/2010 |
|
Builder |
Fukuoka Shipbuilding Co.,Ltd. Fukuoka Japan |
|
Yard number |
F-1278 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 7 Oil tight: 11 |
|
Continuous decks |
1 |
|
Main engine |
1x Makita/MAN-B&W 6S42MC Mk6 - 2 stroke single acting 6 cylinder 420 x 1.764 mm combustion engine Mcr 6.150 kW / 8.356 hp at 136,0 rpm Nsr: 5.535 kW at 131,0 rpm Manufacturer name: Makita Corporation |
|
Propellers |
1x Fixed pitch propeller - aft at 136 rpm Builder: Nakashima Propeller Co., Ltd. |
|
Boilers |
2x Auxiliary boiler Mission OM 10 - CHO 57,00 m² - 6,90 bar each Manufacturer name: Aalborg Industries K.K. 1x Exhaust gas economizer Mission XW - CHR 254,00 m² - 6,9 bar Manufacturer name: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Nishishiba NTAKL-VEX diesel generatorsets each 700 kVA - 560 kW - 836 hp Manufacturer name: Nishishiba Electric Co., Ltd. |
|
Emergency generator |
1x Diesel generatorset 65 kVA - 52 kW - 82 hp |
|
Number of cargo tanks |
20 |
|
Segregations |
20 |
|
Cargo tank capacity |
22.059,81 m³ |
|
Number of tanks |
Ballast: 17 Fresh water: 8 Fuel oil: 8 Lubricating oil: 6 Diesel oil: 5 Chain: 2 Waste water: 2 Potable water: 2 Sea water: 1 Sludge: 1 |
|
Tank capacities 100% |
Diesel oil: 315 m³ Fresh water: 916,38 m³ Fuel oil: 686,43 m³ Lube oil: 65,04 m³ Tank ballast: 7.071,79 m³ |
|
Number of pumps |
12x Cargo pumps each 330 m³/h 8x Cargo pumps each 220 m³/h 2x Ballast pumps each 300 m³/h |
|
Lifting equipment |
1x Hose handling crane - SWL 5,0 t Manufacture name: Kyoritsu Kikai Co., Ltd. |
|
Accommodation |
Officer: 9 Crew: 11 Other: 2 Total: 21 |
|
Commercial manager |
MOL Chemical Tankers Europe AS Tuborg Havnevej 15 2900 Hellerup, O Denmark. |
|
ISM manager |
Unix Line Pte. Ltd. Republic of Singapore |
|
Registered owner |
MOL Chemical Tankers Pte Ltd. 15-01, UIC Building, 5, Shenton Way Singapore 068808 Republic of Singapore |
|
Previous names & owners |
2010 - 05/06/2014 Clipper Mari - Clipper Tank Shipinvest I Ltd. |
|
Latest data adjustment |
12 March 2023 |
