Name |
BOMAR MERCURY |
|
Previous names |
2008 - 09/2011 Gorkem Bay |
|
Type |
Oil / Chemical tanker |
|
IMO-number |
9428889 |
|
Call sign |
9HA2880 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flag |
2008 - 09/2011 Turkey - Call sign: TCTB4 |
|
GT |
4.766 |
|
DWT |
Summer: 7.003 t |
|
NT |
2.295 t |
|
Length |
119,60 m overall 111,85 m between perpendiculars |
|
Breadth |
16,90 m moulded |
|
Draught |
Summer: 6,70 m |
|
Keel to mast end |
37,50 m |
|
Freeboard |
1.679 mm |
|
Depth |
8,40 m |
|
Speed |
13,0 knots ballast 12,0 knots laden |
|
Built |
2008 |
|
Date of completion |
16/07/2008 |
|
Builder |
Umo Shipping Industry & Trade (Umo Gemi Sanayi Ve Ticaret LTD.STI.) Zonguldak Karadeniz Eregli Turkey |
|
Yard number |
01 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MaK 6M32C - 4 stroke 6 cylinder 320 x 480 mm combustion engine 2.999 kW / 4.075 hp at 600 rpm Built: 20/03/2007 Builder: Caterpillar Motoren GmbH - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 160 rpm |
|
Rudder |
1x Becker high lift |
|
Boilers |
1x CHR HTI- GESAB GmbH 62,60 m² - 10,0 bar 2x CHO HTI- GESAB GmbH 76,10 m² - 10,0 bar |
|
Shaft generator |
1x 720 kW driven from gearbox |
|
Generators |
3x MAN main diesel generatorsets each 554 kVA - 443 kW - 602 hp |
|
Emergency generator |
1x Diesel generatorset 224 kVA - 179 kW - 243 hp |
|
Bow thruster |
1x Schottel 450 kW |
|
Number of tanks |
12 + 2 slop tanks |
|
Cargo tanks |
Number: 6 pairs of individual port and starboard tanks, plus 2 slop (deck) tanks Segregations: Capable of 14 Pumps: Individual deepwell pumps in all cargo tanks and slop tanks Pipework: Stainless steel 316 throughout Coating: MarineLine in all tanks Coiled: Yes - stainless steel coils in all cargo and slop tanks; heating medium is secondary thermal oil Heating: Max cargo loading temperature 80°C; can maintain cargo at 65°C Max. Density: 1,54 t/m³ |
|
Total cap. of tanks 98% |
7.894 m³ (excluding slop tanks) |
|
Number of pumps |
12x Cargo pumps each 200 m³/h |
|
Tank capacities |
Fuel: 489,6 m³ |
|
Commerical manager |
North Sea Tankers BV Westblaak 152 3012 KM Rotterdam The Netherlands |
|
ISM manager |
Borealis Denizcilik AS SIddiklar Is Merkezi, Halk Sokak 52/8, Sahrayicedit Mah, Kadikoy 34734 Istanbul Turkey |
|
Registered owner |
BM Chemical Mercury Ltd. (Borealis Maritime Ltd.) Care of North Sea Tankers BV Westblaak 152 3012 KM Rotterdam The Netherlands |
|
Previous names & owner |
2008 - 09/2011 Gorkem Bay - Birlesik Shipping, Istanbul, Turkey |
|
Latest data adjustment |
17 December 2021 |
