Name |
CHEMBULK WESTPORT |
|
Type |
Oil / Chemical tanker |
|
IMO-number |
9317858 |
|
Call sign |
3EDZ7 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
18.760 t Suez: 19.689,71 t |
|
DWT |
Summer: 32.044,33 t |
|
NT |
9.393 t Suez: 17.874,75 t Panama: 15.677 t |
|
Length |
170,00 m overall |
|
Breadth |
25,60 m moulded |
|
Draught |
Summer: 11,36 m |
|
Moulded L x B x D |
162,00 x 25,60 x 16,30 m |
|
Registered L x B x D |
162,86 x 25,60 x 16,30 m |
|
Keel to masthead |
39,60 m |
|
Air draft |
Lightship: 37,01 m Normal ballast: 32,70 m At loaded summer deadweight: 28,24 m |
|
Freeboard |
Summer: 4.965 mm Winter: 5.201 mm |
|
Depth |
16,30 m moulded |
|
Speed |
Service: 14,7 knots Max.: 16,8 knots |
|
Built |
2005 |
|
Keel laid |
20.06.2005 |
|
Launch date |
28.09.2005 |
|
Date of completion |
26.12.2005 |
|
Builder |
Kitanihon Shipbuilding Co., Ltd. |
|
Yard number |
360 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Mitsubishi/Akasaka 6UEC52LS - 2 stroke single acting 6 cylinder 520 x 1.850 mm diesel engine 7.980 kW / 10.850 hp at 120,0 rpm Manufacturer: Akasaka Diesels Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 460 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler- 9,0 bar Evaporation: 19,31 t/h Manufacturer: Miura Protec Co., Ltd. |
|
Generators |
4x Generators total 2.350 kVA |
|
Cargo tank capacity 98% |
36.637,95 m³ excluding slop tanks |
|
Pumps |
12x Centrifugal cargo pumps 330 m³/h 2x Centrifugal cargo pumps 220 m³/h 2x Centrifugal ballast pumps 650 m³/h |
|
Manifolds |
Bow to centre manifold: 84,15 m Stern to centre manifold: 85,85 m Distance bridge front to centre of manifold: 60,45 m Distance between cargo manifold centres: 1.500 mm Distance ships rail to manifold: 5.400 mm Distance manifold to ships side: 5.670 mm Top of rail to centre of manifold: 1.500 mm Distance main deck to centre of manifold: 2.970 mm |
|
Tank capacities |
Fuel oil: 1.625 m³ Fresh water: 1.374 m³ Water ballast: 12.540 m³ |
|
Lifting equipment |
2x Derrick - SWL 0,9 t 1x Crane - SWL 10,0 t |
|
Manager |
Maritime Management Group Pte. Ltd. |
|
Technical operator |
M.T.M. Ship Management Pte. Ltd. Republic of Singapore |
|
Commercial manager |
BLT Chembulk Group |
|
Owner |
Doun Kisen |
|
Disponent owner |
Chembulk Trading II LLC |
|
Registered owner |
Mi-Das Line S.A |
|
Latest data adjustment |
21 October 2014 |
