Westerschelde 24 April 2017 |
 |
 |
 |
 |
|||
| Westerschelde 24/04/17 | Westerschelde 15/07/14 | Westerschelde 15/07/14 | Westerschelde 28/08/16 | |||
|
Name |
STEN BOTHNIA |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9378735 |
|
Call sign |
LAEF7 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
11.935 t |
|
DWT |
Summer: 16.611 t |
|
NT |
5.133 t |
|
Length |
144,35 m overall 133,87 m between perpendiculars |
|
Breadth |
23,20 m extreme 23,02 m moulded |
|
Draught |
8,90 m |
|
Keel to top of mast |
44,31 m |
|
Freeboard |
3.521 mm |
|
Depth |
12,40 m moulded |
|
Speed |
Service: 14,0 knots |
|
Built |
2008 |
|
Keel laid |
28/08/2007 |
|
Launch date |
08/12/2007 |
|
Date of completion |
20/11/2008 |
|
Builder |
Jiangnan Shipyard (Group) Co., Ltd. Feng Chan Village, Chang Xing Town Chongmin County Shanghai China |
|
Yard number |
H2384 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Bulkheads |
Transverse: 8 Longitudinal: 1 |
|
Main engine |
1x Wärtsilä 6L46C - 4 stroke single acting 6 cylinder 460 x 580 mm combustion engine Mcr 6.300 kW / 8.565 hp at 500 rpm Builder: Wärtsilä Finland Oy - Finland |
|
Propellers |
1x Controllable pitch propeller 4 blades Builder: Wärtsilä Norway AS |
|
Boilers |
1x Auxiliary boiler, composite AQ-16 1x Auxiliary boiler, oil/gas fired AQ-9 Builder: Aalborg Industries A/S |
|
Shaft generator |
1x AVK - 1.500 kW |
|
Generators |
2x Wärtsilä W4L20 - 4 stroke 4 cylinder 200 x 280 mm diesel engine each Mcr 800 kW at 900 rpm connected with generators each 700 kW 1x Wärtsilä W6L20 - 4 stroke 6 cylinder 200 x 280 mm diesel engine Mcr 1.200 kW at 900 rpm connected with generators 1.100 kW Builder: Wärtsilä Finland Oy |
|
Emergency generator |
1x Sisu diesel 634 DSBG generatorset |
|
Bow thruster |
1x Brunvoll tunnel thruster 750 kW / 1.020 bhp, forward |
|
Number of tanks |
12 + 2 slop tanks |
|
Tank capacity 98% |
Liquid: 18.491 m³ |
|
Number of slop tanks |
3 |
|
Slop tank capacity 98% |
681 m³ |
|
Total capacity 98% |
19.172 m³ |
|
Number of segregations |
8 |
|
Cargo pumps |
12x Framo cargo pumps each 300 m³/h 2x Framo cargo pump 150 m³/h + portable pumps |
|
Pumping capacity |
2.100 m³/h |
|
Heating capacity |
70°C |
|
Manifolds |
Bow to centre of manifold: 71,80 m |
|
Tank capacitires |
Ballast: 8.179,7 m³ Fuel oil: 580 m³ Diesel oil: 74,8 m³ Fresh water: 502 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Lifting equipment |
1x Hose crane - SWL 5,0 t |
|
Crew size |
18 |
|
ISM & commercial manager |
Stenersen Rederiet AS Edvard Griegs Vei 1 5059 Bergen Norway |
|
Registered owner |
Stenship KS Edvard Griegs Vei 1 5059 Bergen Norway |
|
Latest data adjustment |
05 March 2023 |
