Antwerpen 03 May 2014 |
 |
| Antwerpen 16/05/14 |
|
Name |
VANQUISH |
|
Type |
Inland tanker |
|
ENI-number |
02332793 |
|
Flag |
The Netherlands |
|
Port of registry |
Dordrecht |
|
Tonnage |
3.528 t |
|
Length |
110,00 m |
|
Breadth |
11,5 m |
|
Draught |
4,20 m |
|
Depth |
5,40 m |
|
Built |
2010 |
|
Date of completion |
15.03.2010 |
|
Builder casco |
Nantong Hongqiang Shipyard |
|
Builder completion |
TeamCo Shipyard |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi S 16 R-C2MPTK diesel engine 1.250 kW / 1.700 hp at 1.600 rpm |
|
Gearbox |
Masson Marine type MM W7250 - reduction: 5,031:1 |
|
Propellers |
1x 5 blades propeller diameter 1.750 mm with Van de Giessen Optima nozzle diameter 1.762 mm |
|
Generators |
1x Caterpillar C18 ACERT diesel engine coupled with Marathon 572 RSL 4030 generator 525 kVA 1x Caterpillar C18 ACERT diesel engine coupled with Marathon 572 RSL 4027 generators 107 kVA 1x Perkins 4.4 TW2GM diesel engine coupled with Marathon 363 CSL 1607 generator 81 kVA |
|
Bow thruster |
1x Caterpillar 510 hp - Verhaar Omega 31130-4k - 375 kW at 1.780 rpm |
|
Cargo tank capacity |
3.785 m³ |
|
Pumps |
2x Screw pumps Bornemann type EPS500 each 500 m³/h driving by electric motor 200 kW 1x Twin screw pump type EPS200 - 200 m³/h driving by electric motor 75 kW 1x Twin screw pump type EPS10 - 10 m³/h driving by electric motor 5,5 kW |
|
Owner |
Vanquish BV |
|
Latest data adjustment |
12 January 2015 |
