Name
|
LUCY ESSBERGER
|
|
Previous names
|
12/1997 - 2010 Multitank Badenia
|
|
Type
|
Chemical tanker
|
|
IMO-number
|
9140827
|
|
Call sign
|
PCDJ
|
|
Flag
|
The Netherlands
|
|
Port of registry
|
Dordrecht
|
|
Previous flags
|
1997 - 1998 Germany, Hamburg
1998 - 1998 Liberia, Monrovia
1998 - 1998 Germany, Hamburg
1998 - 2007 Liberia, Monrovia
2007 - 2007 Germany, Hamburg
2007 - 2008 Liberia, Monrovia
2008 - 2009 Germany, Hamburg
2009 - 2010 Liberia, Monrovia
|
|
GT
|
3.726 t
Suez: 4.081 t
|
|
DWT
|
Summer: 5.846 t
|
|
NT
|
1.673 t
Panama: 3.189 t
|
|
Length
|
99,89 m overall
94,90 m between perpendiculars
|
|
Breadth
|
16,50 m extreme
|
|
Draught
|
6,80 m
|
|
Keel to masthead
|
35,60 m
|
|
Forecastle
|
7,80 m
|
|
Poop
|
24,05 m
|
|
Freeboard
|
Summer: 1.525 mm
|
|
Depth
|
8,30 m moulded
|
|
Speed
|
15,0 knots
|
|
Built
|
1997
|
|
Keel laid
|
12/12/1996
|
|
Launch date
|
12/08/1997
|
|
Date of completion
|
19/12/1997
|
|
Builder
|
ENVC - Estaleiros Navais de Viana do Castelo, S.A.
Avenida Praia do Norte
4901-851 Viana do Castelo
Portugal
|
|
Yard number
|
193
|
|
Hull material
|
Shipbuilding steel (standard)
|
|
Hull type
|
Double bottom
|
|
Watertight bulkheads
|
11
|
|
Continuous decks
|
1
|
|
Main engine
|
1x MAN-B&W 7S35MC - 2 stroke 7 cylinder 350 x 1.400 mm combustion engine 4.165 kW / 5.662 hp at 145 rpm
Year of Manufacture: 1996
Manufacturer: MAN-B&W Diesel A/S Frederikshavn
Niels Juels Vej 15
9900 Frederikshavn
Kingdom of Denmark
|
|
Propellers
|
1x Controllable pitch propeller - aft
|
|
Boilers
|
1x Thermal oil heater, exhaust gas heated - 10,0 bar
Heating surface: 82,0 m²
2x Thermal oil heater, oil fired - 10,0 bar
Heating surface: 61,6 m²
Year of manufacture: 1995
Manufacturer: Keu Energie- und Umwelt- Technik GmbH Niederlassung Wiesloch
Baiertaler Str. 92-98
69168 Wiesloch
Federal Republic of Germany
|
|
Electric installations
|
2x Plant 380/220 V - 790 kVA
1x Plant 380 V - 688 kVA
1x Plant 380 V - 103 kVA
|
|
Shaft generator
|
1x 688 kVA
|
|
Generators
|
2x Main diesel generatorsets each 790 kVA
|
|
Emergency generator
|
1x Diesel generatorset 103 kVA
|
|
Compressed air receivers
|
1x Receiver 500 litres - 40,0 bar
2x Receivers each 1.000 litres - 30,0 bar
1x Receiver 200 litres - 30,0 bar
1x Receiver 80 litres - 30,0 bar
2x Receivers each 1.000 litres - 8,0 bar
|
|
Bow thruster
|
1x Fixed pitch propeller SCHOTTEL - 299,99 kW / 402,3 bhp, forward
|
|
Number of cargo tanks
|
20
Seg 1: 350 m³ (1 P / S)
Seg 2: 641,4 m³ (2 P / S)
Seg 3: 785,7 m³ (3 P / S)
Seg 4: 212,7 m³ (4 P / S)
Seg 5: 796 m³ (5 P / S)
Seg 6: 1.113,2 m³ (6 P / S)
Seg 7: 749,2 m³ (7 P / S)
Seg 8: 312,8 m³ (8 P / S)
Seg 9: 476,6 m³ (9 P / S + 10 P / S)
|
|
Liquid cargo
|
6.075 m³
|
|
Total cubic capacity 98%
|
5.950,0 m³ excluding slop tanks
|
|
Pumping systems
|
20x Centrifugal cargo pumps each 100 m³/h
1x Centrifugal cargo pump - 70 m³/h
2x Centrifugal ballast pumps each 200 m³/h
|
|
Tank capacities
|
Fuel oil: 363 m³
Ballast water: 2.439,1 m³
|
|
Manifolds
|
Bow to centre manifold: 50,71 m
Stern to centre manifold: 49,22 m
Distance bridge front to centre of manifold: 27,29 m
Distance between cargo manifold centres: 450 mm
Distance ships rail to manifold: 3.150 mm
Distance manifold to ships side: 3.350 mm
Distance main deck to centre of manifold: 2.120 mm
|
|
Anchor equipment
|
3x Anchors weight each 2.640 kg
Chain length: 467,50 m
Diameter: 40 mm
|
|
Lifting equipment
|
1x Crane - SWL 3,0 t
2x Derricks - SWL 1,0 t each
|
|
Crew size
|
18
|
|
Manager
|
John T. Essberger G.m.b.H. & Co. K.G
Hamburg
Germany
|
|
Previous managers
|
-
12/1997 - 2010 Christian F. Ahrenkiel G.m.b.H & Co., Hamburg – Germany
-
2010 - 05/2010 John T. Essberger G.m.b.H. & Co. K.G., Hamburg - Germany
-
05/2010 - 12/2016 Essberger Tankers (John T. Essberger B.V.), Dordrecht - The Netherlands
|
|
Owner
|
Lucy Essberger Tankreederei G.m.b.H. & Co. K.G.
Dordrecht
The Netherlands
|
|
Previous owners
|
-
1997 - 2009 Tankreederei Ahrenkiel GmbH
-
2009 - 2010 Partenreederei MT "Multitank Badenia"
-
2010 – 05/2010 John T. Essberger G.m.b.H. & Co. K.G., Hamburg – Germany
-
05/2010 – 09/2016 Wieldrecht Shipping B.V., Dordrecht - The Netherlands
|
|
Renamed
|
26/06/2020 Sokrat
Russia, Petropavlovsk-Kamchatskiy - Call sign: UBMU3
Owner: Morskoy Standart-Bunker LLC
|
|
Latest data adjustment
|
23 September 2023
|
