Westerschelde 18 August 2017 |
 |
 |
 |
||
| Antwerpen 07/05/15 | Antwerpen 07/05/15 | Westerschelde 23/12/19 | ||
|
Name |
CHEMROAD WING |
|
Type |
Oil / Chemical tanker |
|
IMO-number |
9309502 |
|
Call sign |
3EAB8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
18.733 t registered |
|
DWT |
Summer: 32.051 t |
|
NT |
9.393 t registered |
|
Length |
170,00 m overall |
|
Breadth |
25,60 m moulded |
|
Draught |
Summer: 11,36 m |
|
Moulded L x B x D |
162,00 x 25,60 x 16,30 m |
|
Registered L x B x D |
162,86 x 25,60 x 16,30 m |
|
Freeboard |
4.965 mm |
|
Depth |
16,30 m |
|
Speed |
Max.: 16,8 knots Service: 14,5 knots |
|
Built |
2005 |
|
Keel laid |
31/08/2004 |
|
Launch date |
24/12/2004 |
|
Date of completion |
28/03/2005 |
|
Builder |
Kitanihon Shipbuilding Co. Ltd. Hachinohe Japan |
|
Yard number |
356 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi 6UEC52LS - 2 stroke single acting 6 cylinder 520 x 1.850 mm combustion engine 7.980 kW / 10.850 hp at 120,0 rpm Manufacturer: Akasaka Diesels Ltd., Shizuoka - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 460 mm |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary vertical boiler - 9,0 bar Evaporation: 18,94 t/h Manufacturer: Miura Protec Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 650 kW |
|
Number of cargo tanks |
14 |
|
Cargo tank capacity |
37.391 m³ |
|
Tank capacities |
Fuel oil: 1.625 m³ Fresh water: 491 m³ Water ballast: 12.540 m³ |
|
Pumps |
14x cargo pump each 330 m³/h |
|
Lifting equipment |
1x Crane - SWL 0,9 t 1x Crane - SWL 3,0 t 1x Crane - SWL 10,0 t |
|
Crew size |
25 |
|
Manager |
Iino Marine Services Co. Ltd. Uchisaixai-cho 2-chome Chiyoda-ku Tokyo-to 100-0011 Japan |
|
Registered owner |
Chemroad Wing Navigation S.A. |
|
Latest data adjustment |
22 September 2020 |
