Westerschelde 11 June 2015 |
 |
 |
 |
||
| Westerschelde 13/07/17 | Antwerpen 06/01/20 | Antwerpen 06/01/20 | ||
|
Name |
PATRAS |
|
Previous names |
2007 - 05/2010 Gan Sword |
|
Type |
Tanker for chemicals & Oil products |
|
IMO-number |
9348297 |
|
Call sign |
9HDA9 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2007 - 2007 Bahamas, Nassau |
|
GT |
12.137 t |
|
DWT |
Summer: 16.744 t |
|
NT |
5.492 t |
|
Length |
145,05 m overall 136,60 m between perpendiculars |
|
Breadth |
23,00 m |
|
Draught |
9,01 m |
|
Depth |
12,40 m |
|
Speed |
Max. 14,8 knots |
|
Built |
2007 |
|
Keel laid |
10/12/2005 |
|
Date of completion |
20/09/2007 |
|
Builder |
Yardimci Shipyard (Yardimci Gemi Insaa A.S.) Istanbul Turkey |
|
Yard number |
52 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN B&W 6L48/60B - 6 cylinder diesel engine 6.300 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
Auxiliary boiler, composite Auxiliary boiler, oil/gas fired Builder: Garioni Naval, Castelmella - Italy |
|
Shaft generator |
1x 1.875 kVA |
|
Generators |
3x Caterpillar 3508B main diesel generatorsets total 2.550 kVA |
|
Emergency generator |
1x MAN D2866 TE diesel generatorset 187 kVA Builder: MAN Truck & Bus AG - GE Motoren-Nürnberg - Germany |
|
Bow thruster |
1x 800 kW |
|
Number of tanks |
12 |
|
Cargo tank capacity |
19.624 m³ |
|
Number of slop tanks |
2 |
|
Pumps |
Unloading capacity per tank: 358 m³/h Total unloading capacity: 2.100 m³/h |
|
Tank capacities |
IFO: 581 m³ MGO: 105 m³ Ballast capacity: 7.716 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Manager |
Harren Tanker Management GmbH & Co. KG Hermann-Hollerith-Str. 10 28355 Bremen Germany |
|
Previous managers |
2007 - 2010 Dunya Denizcilik ve Ticaret A.S. |
|
Registered owner |
Harren Chemical AS Haakon VII's gate 5 0161 Oslo Norway |
|
Previous owners |
2007 - 2010 Gan-Sword Co. Ltd. 2010 - 2010 CIT Caspian Investment & Trading GmbH & Co. KG 2010 - 2010 CIT Caspian Investment & Trading GmbH & Co. KG MS GAN-Sword |
|
Latest data adjustment |
10 April 2020 |
