Westerschelde 06 August 2015 |
 |
| Westerschelde 21/10/17 |
|
Name |
NORDIC PIA |
|
Previous names |
2006 Launch as: Grazia |
|
Type |
Oil and chemical carrier |
|
IMO-number |
9340104 |
|
Call sign |
9V2534 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
12.2006 - 04.2014 Liberia, Monrovia |
|
GT |
24.112 t registered |
|
DWT |
Summer: 38.395,86 t |
|
NT |
11.118 t registered |
|
Displacement |
47.849 t |
|
Length |
183,00 m overall 174,50 m between perpendiculars |
|
Breadth |
27,40 m moulded |
|
Draught |
11,40 m |
|
Air draft |
37,25 m |
|
Freeboard |
Summer: 5.213 mm Winter: 5.460 mm |
|
Depth |
16,80 m moulded |
|
Speed |
Service: 15,2 knots |
|
Built |
2006 |
|
Keel laid |
06/02/2006 |
|
Launch date |
16/04/2006 |
|
Delivery date |
28/08/2006 |
|
Builder |
CSSC Offshore and Marine Engineering (Group) Company Limited |
|
Yard number |
04130009 |
|
Hull material |
High strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 6 Oil tight: 6 Non tight: 1 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN B&W 6S50MCC - 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW / 12.713 bhp at 127,0 rpm Manufacturer: Dalian Marine Diesel Works |
|
Propellers |
1x Fixed pitch propeller Manufacturer: Wärtsilä Cme Zhenjiang Propeller Co., Ltd. |
|
Boilers |
1x Exhaust Gas Boiler AQ-2 - 7,0 bar 1x Fired Boiler AQ-18 - 7,0 bar |
|
Generators |
3x Main diesel generatorsets each 910 kW Manufacturer: Zhenjiang Marine Diesel Engine Works |
|
Number of cargo tanks |
10 |
|
Cargo tank capacity 98% |
37.963,20 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
5.480,90 m³ |
|
Total tank capacity |
43.443,40 m³ |
|
Segregation |
5x Double valve |
|
Tank coating |
Pure epoxy |
|
Pumps |
10x Each 540 m³ submerged centrifugal type 2x Each 300 m³ submerged centrifugal type 1x 100 m³ submerged centrifugal type 1x 150 m³ portable pump 2x Each 1.000 m³ ballast pumps 1x 80 m³ ballast eductor |
|
Number of tanks |
Ballast: 15 Cargo oil: 12 Fuel oil: 10 Lubricating oil: 8 Diesel oil: 4 Fresh water: 4 Waste water: 2 Chain: 1 Cargo oil or ballast water: 1 |
|
Tank capacities 100% |
Diesel Oil: 143,98 m³ / 122,38 t Freshwater: 609,72 m³ Fuel Oil: 1.381,70 m³ / 1.369,26 t Lube Oil: 123,68 m³ / 111,31 t Tank Ballast: 17.607,32 m³ / 18.047,50 t |
|
Lifting equipment |
1x Cargo hose handling crane 1x Engine room crane 1x Provision Crane |
|
Crew |
30 |
|
Manager |
Nordic Tankers A/S |
|
Technical managers |
Colombia shipmanagement & Thome ship management |
|
Commercial manager |
Hafnia management 2900 Hellerup Denmark |
|
Owner |
Nordic Shipholding BV |
|
Registered owner |
Nordic Pia Pte. Ltd. Republic of Singapore |
|
Latest data adjustment |
06 July 2018 |
