Name |
STOLT INSPIRATION |
|
Type |
Tanker for chemicals & oil products |
|
IMO-number |
9102083 |
|
Call sign |
ZCSP8 |
|
Flag |
Cayman Islands |
|
Port of registry |
George Town |
|
Previous flags |
1997 - 2000 Liberia, Monrovia |
|
GT |
24.625 t |
|
DWT |
Summer: 37.205 t |
|
NT |
11.934 t |
|
Length |
176,75 m overall 168,50 m between perpendiculars |
|
Breadth |
31,07 m extreme |
|
Draught |
11,90 |
|
Keel to mast end |
46,96 m |
|
Depth |
15,61 m |
|
Speed |
16,20 knots |
|
Built |
1997 |
|
Keel laid |
28/06/1996 |
|
Launch date |
04/11/1996 |
|
Date of completion |
15/04/1997 |
|
Builder |
Danyard A/S Frederikshavn Denmark |
|
Yard number |
732 |
|
Hull material |
Steel |
|
Hull type |
Double bottom |
|
Bulkheads |
Transverse: 7 |
|
Main engine |
1x Wärtsilä 6R32LN - 4 stroke single acting 6 cylinder 320 x 350 mm combustion engine 2.460 kW / 3.345 hp at 750 rpm 3x Wärtsilä 9R32LN - 4 stroke single acting 6 cylinder 320 x 350 mm combustion engines 3.645 kW / 4.956 hp at 750 rpm Total power: 13.395 kW / 18.213 hp |
|
Propellers |
1x Fixed pitch propeller - aft at 81,0 rpm |
|
Boilers |
4x Auxiliary boiler, exhaust gas heated AV-9 2x Auxiliary boiler, oil/gas fired AQ9 Builder: Aalborg Industries A/S |
|
Generators |
4x Diesel electric oil engines driving: 3x Generators each 3.500kW - 6.600 Volt AC. 1x Generator of 2.350 kW - 6.600 Volt AC connected to 1 electric motor 10.000 kW |
|
Emergency generator |
1x Wärtsilä UD 25 V12 S5D diesel generatorset - 500 kW |
|
Bow thruster |
1x 1.100 kW |
|
Number of tanks |
42 |
|
Cargo tank capacity |
39.808 m³ |
|
Number of pumps |
17x Cargo pimps each 300 m³/h 29x Cargo pimps each 200 m³/h |
|
Tank capacities |
Ballast: 16.348 m³ |
|
ISM & commercial manager |
Stolt Tankers B.V. Westerlaan 5 3016 CK Rotterdam The Netherlands |
|
Previous managers |
1997 - 2002 Stolt-Nielsen Transportation Group Ltd. |
|
Operator |
Stolt Tankers Joint Service - STJS |
|
Registered owner |
Stolt Inspiration B.V. Care of Stolt Tankers BV Westerlaan 5 3016 CK Rotterdam The Netherlands |
|
Latest data adjustment |
12 June 2022 |
