Westerschelde 23 September 2015 |
|
Name |
COSTANZA WONSILD |
|
Type |
Oil tanker - Chemical tanker |
|
IMO-number |
9013658 |
|
Call sign |
ICWG |
|
Flag |
Italy |
|
Port of registry |
Augusta |
|
GT |
2.349 t |
|
DWT |
Summer: 2.698 t |
|
NT |
816 t |
|
Length |
89,60 m overall 80,90 m between perpendiculars |
|
Breadth |
14,00 m |
|
Draught |
5,21 m |
|
Freeboard |
1.361 mm |
|
Depth |
6,55 m |
|
Speed |
13,5 knots |
|
Built |
1994 |
|
Launch date |
25.09.1993 |
|
Date of completion |
25.02.1994 |
|
Builder |
Esercizio Cantieri S.p.A. |
|
Yard number |
765 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Yanmar 6N330-EN - 4 stroke 6 cylinder diesel engine 2.208 kW / 2.999 bhp at 620 rpm Manufacture: Yanmar Diesel Co.Ltd., Amagasaki - Japan |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
2x Oil fired - 1.744 kW/h 1x Exhaust gas - 465 kW/h |
|
Shaft generator |
1x 812 kVA |
|
Generators |
1x 6 cylinder main diesel generatorset 250 kVA - 200 kW - 408 hp 2x 6 cylinder main diesel generatorsets each 450 kVA - 360 kW - 611 hp |
|
Emergency generator |
1x Diesel generatorset 35 kVA - 28 kW - 60 hp |
|
Bow thruster |
1x 297 kW |
|
Number of tanks |
14 |
|
Cargo tank capacity |
3.031 m³ |
|
Segregations |
14 |
|
Manifold |
From bow: 46,95 m From stern: 42,30 m Height above deck: 3,23 m Distance inboard: 2,76 m Between manifolds: 0,80 m |
|
Lifting equipment |
1x Cargo hose crane - SWL 3,0 t @ 10,00 m |
|
Manager |
M.E. Marittima Emiliana S.p.A. (Amoretti armatori Group) |
|
Operator |
Wonsild Tankers, Copenhagen - Denmark / Amoretti Armatori Group, Parma - Italy |
|
Owner |
Nautica Mostra Mercato |
|
Latest data adjustment |
21 October 2015 |
