Westerschelde 12 May 2019 |
 |
 |
 |
 |
 |
||||
| Westerschelde 24/09/15 | Antwerpen 07/05/19 |
Antwerpen 07/05/19 | Westerschelde 06/09/15 | Westerschelde 09/07/17 | ||||
|
Name |
STAV VIKING |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9401556 |
|
Call sign |
LAGZ7 |
|
Flag |
Norway |
|
Port of registry |
Stavanger |
|
GT |
11.935 t |
|
DWT |
Summer: 16.628 t |
|
NT |
5.133 t |
|
Light ship |
5.968 t |
|
Length |
144,05 m overall 133,81 m between perpendiculars |
|
Breadth |
22,99 m extreme |
|
Draught |
8,40 m |
|
Keel to mast end |
44,31 m |
|
Depth |
12,40 m moulded |
|
Speed |
Trial: 15,8 knots Service: 14,8 knots |
|
Built |
2009 |
|
Keel laid |
19/04/2008 |
|
Launch date |
10/07/2008 |
|
Date of completion |
16/04/2009 |
|
Builder |
Jiangnan Shipyard Group Co., Ltd. Shanghai China |
|
Yard number |
H2414 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 6L48/60B - 4 stroke 6 cylinder 480 x 600 mm combustion engine 6.300 kW / 9.789 bhp at 500 rpm |
|
Propellers |
1x Controllable pitch propeller VBS 1460 - 4 blades diameter 5,40 m Manufacturer: MAN B&W Diesel A/S |
|
Boilers |
1x Auxiliary boiler, composite Mission OC - 8,0 bar 1x Auxiliary boiler, oil/gas fired Mission OM - 8,0 bar Manufacturer: Aalborg Industries AS |
|
Shaft generator |
1x AVK 1.500 kVA |
|
Generators |
2x Wärtsilä 4L20 diesel generatorset each 680 kW 1x Wärtsilä 6L20 diesel generatorsets 970 kW Manufacturer: Wärtsilä Finland Oy |
|
Emergency generator |
1x Sisu diesel generatorset |
|
Bow thruster |
1x Hydraulic driven Brunvoll 750 kW |
|
Cargo tank capacity |
19.500 m³ incl. slop |
|
Slop tank capacity |
700 m³ |
|
Pumps |
12x Pumps each 300 m³/h 2x Pumps 150 each m³/h 2x Pumps 75 each m³/h 1x Pump 70 m³/h Type: Centrifugal, deep well, Framo |
|
Manifolds |
Bow to centre manifolds: 72,20 m |
|
Tank capacities |
Ballast: 8.179,9 m³ Drain tank: 100 m³ HFO: 570 m³ Lub oil: 50 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Accommodation |
Total: 16 people One Hospital Lifesaving equipment 18 persons |
|
Commercial manager |
O.H. Meling Tankers KS Paradisveien 28 4012 Stavanger Norway |
|
ISM manager |
OSM Ship Management AS Svinoddveien 12 4836 Arendal, Norway Norway |
|
Previous managers |
2009 - 2015 Det Stavangerske Dampskibbselskab Shipping AS |
|
Owner |
O.H. Meling Tankers AS Paradisveien 28 N-4012 Stavanger Norway |
|
Latest data adjustment |
17 November 2021 |
