Westerschelde 23 January 2020 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 23/01/20 | Westerschelde 09/10/15 | Antwerpen 19/04/18 | Westerschelde 11/04/19 | Westerschelde 30/01/20 | Vlissingen 25/05/16 | |||||
|
Name |
SELANDIA SWAN |
|
Previous names |
2007 - 2008 Besiktas Nordland |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9371787 |
|
Call sign |
OYIN2 |
|
Flag |
Denmark |
|
Port of registry |
Midderfart |
|
Previous flag |
2007 - 2008 Turkey |
|
GT |
11.711 t |
|
DWT |
Summer: 17.998,44 t |
|
NT |
6.027 t |
|
Displacement |
23.412,88 t |
|
Length |
147,50 m overall 140,60 m between perpendiculars |
|
Breadth |
22,41 m extreme |
|
Draught |
Summer: 9,75 m Ballast: 6,25 m |
|
Height from keel to mast |
38,10 m |
|
Air draft |
32,85 m in ballast 28,65 m loaded |
|
Freeboard |
3.119 mm |
|
Depth |
12,60 m moulded |
|
Speed |
11,3 knots loaded 11,1 knots ballast Max: 14,0 knots |
|
Built |
2008 |
|
Keel laid |
21/10/2006 |
|
Launch date |
09/07/2007 |
|
Date of completion |
19/02/2008 |
|
Builder |
Gisan Tuzla Shipyard (Gisan Gemi Insaat San. ve Tic. Ltd. Sti.) Evliya Celebi Mah. Billur Sok. No:11 Istanbul, 34944 Turkey |
|
Yard number |
40 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MaK 7M43C - 4 stroke 7 cylinder 430 x 610 mm combustion engine 6.300 kW / 8.565 hp at 500 rpm Manufacturer: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated 3EXV 5-35-18-57-0 1x Thermal oil heater, oil fired 1V5-O-TFO- 1x Thermal oil heater, oil fired 2V5-O-TFO-030 1x Thermal oil heater, steam heated 4H.STV-TO |
|
Shaft generator |
1x 1.200 kW |
|
Generators |
3x Yanmar 6N2LAA-SV main diesel generatorsets each 1.000 kVA - 800 kW - 1.087 hp |
|
Emergency generator |
1x Diesel generatorset 218 kW |
|
Bow thruster |
1x 750 kW / 1.006 bhp, forward |
|
Number of cargo tanks |
14 + 2 slop tanks |
|
Cargo tank capacity 98% |
20.186,4 m³ |
|
Slop tank capacity 98% |
397,10 m³ |
|
Number of segregations |
14x double valves |
|
Number pumps |
14x Centrifugal cargo pumps each 380 m³/h 2x Centrifugal cargo pumps each 100 m³/h 1x Centrifugal pump 70 m³/h 2x Ballast pumps each 500 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 83,90 m Distance from stern to centre manifold: 63,60 m Distance between manifolds: 1,50 m Distance from ship side to manifold: 4,688 m Distance from deck / tray to manifold: 2,01 m / 0,79 m |
|
Tank capacities |
Ballast: 7.399,69 m³ Lub oil: 38,32 m³ Fresh water: 352,30 m³ Diesel oil: 1183,08 m³ Fuel oil: 700,27 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 56 mm |
|
Lifting equipment |
1x Hose crane - SWL 10,0 t 1x MOB/stores- SWL 2,0 t |
|
Manager |
Uni Tankers A/S Turbinevej 10 5500 Middelfart Denmark |
|
Registered owner |
Uni-Tankers MT "SELANDIA SWAN" ApS Care of Uni-Tankers A/S Middelfart Denmark |
|
Previous names & owners |
2007 - 2008 Besiktas Nordland - Gemini Denta Gemi Insa Nakliyat Ticaret AS - Turkey |
|
Renamed |
10/2022 Frank Gibraltar – Call sign: ZDSG5 Manager: Carl F. Peters GmbH & Co KG - Hamburg, Germany Owner: Reederei TMS Frank GmbH & Co KG, Hamburg - Germany |
|
Latest data adjustment |
01 September 2024 |
