| Westerschelde 10 May 2015 |
 |
 |
||
| Westerschelde 23/07/17 | Westerschelde 05/01/14 | ||
|
Name |
RN PRIVODINO |
|
Previous names |
2009 - 2009 Built as: RN-Privodino |
|
Type |
Tanker for oil & chemicals |
|
IMO-number |
9384459 |
|
Call sign |
5BYQ2 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
19.986 t |
|
DWT |
Summer: 30.720 t |
|
NT |
9.194 t |
|
Displacement |
40.058,64 t |
|
Light ship |
9.337,64 t |
|
Length |
176,10 m overall 169,93 m between perpendiculars |
|
Breadth |
29,82 m extreme |
|
Draught |
9,92 m |
|
Keel to mast end |
39,60 m |
|
Freeboard |
4.113 mm |
|
Depth |
14,00 m |
|
Speed |
Max: 16,2 knots Service: 15,0 knots |
|
Built |
2010 |
|
Keel laid |
27/04/2007 |
|
Delivery date |
12/03/2010 |
|
Builder casco |
Navantia Carenas Puerto Real Puerto Real Spain Yard number: 110 |
|
Builder completion |
Factorias Vulcano S.A. Vigo Spain Yard number: 510 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Number of bulkheads |
10 |
|
Main engine |
1x MAN 9L48/60B - 4 stroke single acting 9 cylinder 480 x 600 mm combustion engine Mcr 10.803 kW / 14.688 hp at 500 rpm Build: 08/2007 Builder: MAN B&W Diesel AG, Augsburg - Germany |
|
Propellers |
1x Controllable pitch propeller 4 blades Builder: Rolls Royce AB |
|
Boilers |
1x Thermal oil heater, exhaust heated 2x Thermal oil heater, oil fired |
|
Shaft generator |
1x 1.250 kW |
|
Generators |
3x MAN 6L21/31 diesel engine each Mcr 1.225 kW connected with generators each 1.225 kW / 400 volt 50 Hz Builder: MAN Diesel & Turbo SE |
|
Emergency generator |
1x MAN D2876 diesel generatorset Builder: MAN Truck & Bus AG - GE Motoren-Nürnberg - Germany |
|
Bow thruster |
1x Tunnel thruster 1.000 kW / 1.360 bhp, forward |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity 98% |
Liquid: 33.976 m³ |
|
Slop tanks capacity 98% |
677 m³ |
|
Number of pumps |
12x Cargo pumps each 500 m³/h |
|
Tank capacities |
Ballast: 15.132,7 m³ Distillate fuel: 160 m³ Residual fuel: 1.230 m³ |
|
Anchor equipment |
Length: 605,00 m Diameter: 64 mm |
|
Lifting equipment |
1x Crane - SWL 10,0 t 1x Crane - SWL 3,0 t |
|
Manager |
Unicom Management Services (Cyprus) Ltd. Maximos Michaelides St 18 Limassol 3106 Cyprus |
|
Previous managers |
2010 - 2010 Rosnefteflot, JSC |
|
Owner |
Rubio Holdings Limited |
|
Previous owners |
2010 - 2011 Lico Leasing, S.A. 2011 - 2012 Naviera Ladoga, A.I.E. |
|
Renamed |
02/2023 Ji Xiang Republic of Panama, Panama City - Call sign: 3E4106 owner & manager: Luena Aquatic Inc. - Republic Seychelles |
|
Latest data adjustment |
03 July 2024 |
