Westerschelde 10 February 2016 |
 |
 |
 |
||
| Westerschelde 10/02/16 | Westerschelde 10/02/16 | Westerschelde 05/05/16 | ||
|
Name |
SIVA ROTTERDAM |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9485863 |
|
Call sign |
3EYW9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
11.640 t registered |
|
DWT |
Summer: 19.995,26 t |
|
NT |
6.126 t registered |
|
Length |
145,53 m overall |
|
Breadth |
23,70 m moulded |
|
Draught |
Summer: 9,71 m |
|
Moulded L x B x D |
137,00 x 23,70 x 13,35 m |
|
Registered L x B x D |
137,92 x 23,70 x 13,35 m |
|
Freeboard |
Summer: 3.665 mm |
|
Depth |
13,35 m moulded |
|
Speed |
Max.: 16,5 knots |
|
Built |
2012 |
|
Keel laid |
24/11/2011 |
|
Launch date |
27/01/2012 |
|
Date of completion |
25/06/2012 |
|
Builder |
Usuki Shipyard Co., Ltd. Usuki Japan |
|
Yard number |
S1731 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Hitachi/MAN-B&W - 2 stroke single acting 6 cylinder 420 x 1.764 mm combustion engine 6.150 kW / 8.361 hp at 136,0 rpm Manufacturer: Hitachi Zosen Corporation Innoshima Works |
|
Propeller shaft |
1x Sea water lubrication shaft Diameter: 420 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary Boiler WTB - 9,0 kg/cm² Heating surface: 184,2 m² 1x Economizer Exhaust gas boiler - 14,0 kg/cm² Heating surface: 1191,3 m² Manufacturer: Miura Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 750 kVA / 450 Volt |
|
Cargo tank capacity 98% |
Liquid: 21.017 m³ |
|
Segregations |
20 |
|
Tank capacities |
Fuel oil: 1.033,5 m³ Fresh water: 612,9 m³ Water ballast: 7.120 m³ |
|
Manager |
Executive Ship Management Pte., Ltd. |
|
Operator |
Siva chemicals Pte., Ltd. 8 Temasek Boulevard # 22-02 Suntec Tower Three Singapore City Republic of Singapore |
|
Registered owner |
Latin King S.A. Copenhagen Denmark |
|
Renamed |
2017 FG Rotterdam Republic of Panama, Panama City - Call sign: 3EYW9 Owner: Ocean Trinity PO No.2 S.A. ISM & commercial: Taikun Shipping Co., Ltd.,Haeundae-gu, Busan, 48059 - South Korea |
|
Latest data adjustment |
14 November 2023 |
