Westerschelde 22 April 2014 |
|
Name |
DENIZ A |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9539949 |
|
Call sign |
9HA2855 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
Turkey, Istanbul - Call sign: TCXW9 |
|
GT |
3.153 t |
|
DWT |
Summer: 4.753,15 t Winter: 4.550 t |
|
NT |
1.392 t |
|
Length |
99,91 m overall 94,09 m between perpendiculars |
|
Breadth |
15,00 m |
|
Draught |
6,06 m |
|
Freeboard |
1.404 mm |
|
Depth |
7,40 m |
|
Speed |
13,5 knots |
|
Built |
2010 |
|
Date of completion |
05.05.2010 |
|
Builder |
Ceksan Gemi Insa Celik Konst. San Ve Tic. A.S |
|
Yard number |
45 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W-STX 8L28/32A - 4 stroke 6 cylinder 128 x 155 mm diesel engine 1.961 kW / 2.665 hp at 750 rpm Builder: MAN Nutzfahrzauge AG - Germany |
|
Propellers |
1x Screw propeller solid |
|
Boilers |
1x CHR 70,00 m² / 10,0 bar |
|
Shaft generator |
1x 713 kVA - 570 kW |
|
Generators |
2x Diesel generatorsets each 731 kVA - 585 kW - 840 hp 1x Diesel generatorset 275 kVA - 220 kW - 420 hp |
|
Bow thruster |
298 kW |
|
Number of cargo tanks |
10x Marine line coated cargo tanks |
|
Cargo tank cap. 98% |
4.585 m³ m³ excl. slop tanks |
|
Slop tanks |
2 |
|
Slop tank capacity |
361,86 m³ |
|
Segregation |
12 grades |
|
Cargo pumps |
10x Centrifugal each 200 m³/h |
|
Loading rate |
800 m³/h |
|
Discharging rate |
600 m³/h |
|
Tank capacities 100% |
Fuel oil: 229,91 m³ Diesel oil: 67,28 m³ Ballast water: 2.031 m³ |
|
Lifting equipment |
1x Centre crane - SWL 5,0 t |
|
Manager |
Transtekmarine Gemi Isletim Mete Caddesi 16/5 Gumussuyu Mah, Beyoglu |
|
Operator |
Chemfleet |
|
Owner |
Tyburn Shipping Ltd. |
|
Latest data adjustment |
08 March 2016 |
