Name |
GRANATO |
|
Type |
Tanker for oil and chemicals |
|
IMO-number |
9201774 |
|
Call sign |
IBOH |
|
Flag |
Italy |
|
Port of registry |
Ancona |
|
GRT |
5.006 t |
|
DWT |
Summer: 7.071 t |
|
NRT |
2.100 t |
|
Length |
119,10 m overall |
|
Breadth |
16,40 m moulded |
|
Draught |
Summer: 6,70 m |
|
Moulded L x B x D |
119,10 x 16,40 x 8,40 m |
|
Registered L x B x D |
111,42 x 16,40 x 8,40 m |
|
Keel to mast end |
30,00 m |
|
Freeboard |
Summer: 1.710 mm |
|
Depth |
8,40 m moulded |
|
Speed |
13,5 knots |
|
Built |
2000 |
|
Keel laid |
30/09/1998 |
|
Launch date |
26/02/2000 |
|
Date of completion |
20/06/2000 |
|
Builder |
Cantiere Navale Mario Morini Ancona Italy |
|
Yard number |
266 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Wärtsilä 6LSW38 - 4 stroke single acting 6 cylinder 380 x 475 mm combustion engine 3.960 kW / 5.384 hp at 600 rpm Manufacturer: Wärtsilä Switzerland Ltd. Logistics Center Moerdijk |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 360 mm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
2x Main boilers thermal oil 1.500.000 kcal each - 0,55 MPa 1x Exhaust gas boiler 520.000 kcal - 1,20 MPa Manufacturer: Bono Energia Canon Bono Energia |
|
Generators |
3x Wärtsilä W6L170 - 6 cylinder single acting diesel generatorsets each 620 kW at 1.800 rpm |
|
Bow thruster |
1x Schottel 400 kW |
|
Number of tanks |
13 + 2 Slop tanks |
|
Total capacity |
100%: 7.514,5 m³ 98%: 7.266,67 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
97,50 m³ each |
|
Number of pumps |
11x cargo pumps eaxh 170 m³/h 4x Cargo pumps each 50 m³/h |
|
Tank capacities |
Heavy fuel oil: 370 m³ Marine diesel oil: 60 m³ Fresh water: 166 m³ |
|
Pumps |
11x Framo deepwell centrifugal hydraulic driven 175 m³/h each 1x Framo portable centrifugal spare pump 70 m³/h 2x Framo deepwell centrifugal hydraulic driven for slop tank 50 m³/h each |
|
Operator |
Finbeta S.p.A. |
|
Owner |
Finbeta S.p.A. Via Nazionale Piemonte 4 17100 Savona Italy |
|
Sister ships |
Smeraldo |
|
Renamed |
09/2020 Darmik Turkey, Istanbul - Call sign: TCA6037 Owner: Beykim Petrolculuk Gemi Isletmeciligi Sanayi Ve Ticaret A.S., Istanbul - Turkey Manager: Beykar Denizcilik Gemi Kiralama Turizm Nakliyat Petrolculuk Ticaret A.S., Istanbul - Turkey |
|
Latest data adjustment |
13 January 2022 |
