Westerschelde 08 June 2017 |
 |
 |
 |
||
| Westerschelde 20/01/14 | Westerschelde 20/01/14 | Westerschelde 31/01/20 | ||
|
Name |
CAROLINE ESSBERGER |
|
Type |
Tanker for chemicals and oil products |
|
Main products |
Chemicals |
|
IMO-number |
9439151 |
|
Call sign |
PBUD |
|
Flag |
The Netherlands |
|
Port of registry |
Dordrecht |
|
GT |
5.642 t |
|
DWT |
Summer: 8.506 t |
|
NT |
2.561 t |
|
Length |
123,25 m overall 115,97 m between perpendiculars |
|
Breadth |
17,20 m moulded |
|
Draught |
7,50 m |
|
Keel to mast end |
37,00 m |
|
Freeboard |
1.710 mm |
|
Depth |
9,21 m moulded |
|
Speed |
14,0 knots |
|
Built |
2009 |
|
Keel laid |
15/05/2008 |
|
Launch date |
29/05/2009 |
|
Date of completion |
05/08/2009 |
|
Builder |
Med Marine Kilavuzluk Ve Romorkaj Hizmetleri Insaat Sanayi Ve Tic. A.S. Istanbul Turkey |
|
Yard number |
07 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M43C - 4 stroke single acting 6 cylinder 430 x 610 mm combustion engine 5.400 kW / 7.337 bhp at 500 rpm Built: 14/08/2008 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHS 19,40 m² - 16,0 bar 1x CHR 197,00 m² - 10,0 bar 2x CHO 57,00 m² - 10,0 bar |
|
Shaft generator |
1x 1.375 kVA - 1.100 kW |
|
Generators |
3x MAN D2842 LE301 main diesel generatorsets each 731 kVA - 585 kW - 700 hp |
|
Emergency generator |
1x MAN D2866 LXE20 diesel generatorset 163 kVA - 130 kW - 177 hp |
|
Thrusters |
1x 430 kW, forward |
|
Number of tanks |
16 + 2 slop tanks |
|
Cargo tank capacity |
8.921 m³ |
|
Number of pumps |
12x Cargo pumps each 350 m³/h 4x Cargo pumps each 150 m³/h |
|
Tank capacities |
Fuel: 445,1 m³ Ballast: 4.039,1 m³ |
|
Anchor equipment |
Length: 522,50 m Diameter: 48 mm |
|
ISM & commercial manager |
John T. Essberger G.m.b.H. & Co. K.G. Palmaille 45 22767 Hamburg Germany |
|
Previous manager |
08/2009 - 12/2016 Essberger Tankers (John T. Essberger B.V.), Dordrecht - The Netherlands |
|
Registered owner |
Caroline Essberger' Tankreederei GmbH & Co. KG Care of John T Essberger GmbH & Co KG Palmaille 45 22767 Hamburg Germany |
|
Previous names & owners |
08/2009 - 11/2016 Caroline Essberger - Engelina B.V., Dordrecht - The Netherlands |
|
Latest data adjustment |
31 August 2022 |
