Westerschelde 27 December 2018 |
 |
| Westerschelde 07/10/16 |
|
Name |
CHEM NORMA |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9486192 |
|
Call sign |
V7SO9 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
11.939 t registered |
|
DWT |
Summer: 17.095 t |
|
NT |
5.180 t registered |
|
Length |
144,80 m overall |
|
Breadth |
23,00 m moulded |
|
Draught |
Summer: 8,92 m |
|
Moulded L x B x D |
134,50 x 23,00 x 12,40 m |
|
Registered L x B x D |
144,80 x 23,00 x 12,40 m |
|
Keel to mast end |
42,30 m |
|
Freeboard |
Summer: 3.512 mm |
|
Depth |
12,40 m moulded |
|
Speed |
13,0 knots |
|
Built |
2009 |
|
Keel laid |
22/11/2008 |
|
Date of completion |
05/11/2009 |
|
Builder |
Ningbo Xinle Shipbuilding Co., Ltd. Ningbo China |
|
Yard number |
XL-112 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 7S35MC - 2 stroke single acting 7 cylinder 350 x 1.400 mm combustion engine 5.180 kW / 7.043 hp at 173,0 rpm Manufacturer: STX Engine Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 13,2 bar Evaporation: 2,60 t/h 1x Auxiliary vertical boiler - 13,2 bar Evaporation: 2,20 t/h Manufacturer: Aalborg Industries Pte. Ltd. |
|
Shaft generator |
3x Main diesel generatorsets each 640 kW |
|
Bow thruster |
1x 690 kW |
|
Number of tanks |
12 |
|
Number of slop tanks |
2 |
|
Cargo tank capacity |
19.445 m³ |
|
Tank coating |
Marineline |
|
Number of pumps |
12x Cargo pumps each 335m³/h |
|
Tank capacities |
Fuel oil: 739 m³ Fresh water: 440 m³ Water ballast: 8.005 m³ |
|
ISM & Commerical manager |
ASM Maritime B.V. Strawinskylaan 1979 World Trade Center, Tower I, Level 7 1077 XX Amsterdam The Netherlands |
|
Registered owner |
Chem Norma S.A. c/o Ace Quantum Chemical Tankers CV Amsterdam The Netherlands |
|
Latest data adjustment |
24 August 2021 |
