Westerschelde 16 March 2015 |
|
Name |
CAPE BACTON |
|
Previous names |
2004 - 04.2005 Chabua Amiredjibi 04.2005 - 08.2005 Celebes Wind 08.2005 - 01.2006 Chambua Amiredjibi |
|
Type |
Chemical tanker |
|
IMO-number |
9264283 |
|
Call sign |
V7FK8 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
25.108 t |
|
DWT |
Summer: 39.999 t |
|
NT |
8.346 t Suez: 23.100 t Panama: 20.892 t |
|
Length |
176,00 m overall 168,00 m between perpendiculars |
|
Breadth |
31,00 m extreme |
|
Draught |
Summer: 11,04 m |
|
Keel to mast |
48,04 m |
|
Depth |
17,00 m |
|
Speed |
14,0 knots |
|
Built |
2004 |
|
Keel laid |
20.11.2003 |
|
Launch date |
25.02.2004 |
|
Date of completion |
23.04.2004 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. |
|
Yard number |
0144 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x B&W-Hyundai 6 S 50 MC-C - 2 stroke 6 cylinder diesel engine 8.562 kW Builder: Hyundai Heavy Industries Co.Ltd.(B&W), Ulsan - South Korea |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1x Auxiliary boiler, exhaust gas heated |
|
Generators |
3x MAN 6L23/30 main diesel generatorsets each 925 kVA |
|
Emergency generator |
1x 624 DSBG diesel generatorset |
|
Bow thruster |
1x 900 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 98% |
42.681 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
2.068 m³ |
|
Total tank capacity 98% |
44.749 m³ |
|
Segregations |
7 |
|
Tank coating |
Epoxy |
|
Pumps |
12x Cargo pumps each 500 m³/h 2x Cargo pumps each 200 m³/h |
|
Manifolds |
Bow centre manifolds: 89,93 m |
|
Tank capacities |
Ballast: 20.712 m³ |
|
Anchor equipment |
Length: 632,50 m Diameter: 70 mm |
|
Lifting equipment |
1x Derricks - SWL 10,0 t |
|
Manager |
UPT - United Product Tankers GmbH & Co., KG |
|
Operator |
Columbia Shipmanagement Ltd. |
|
Registered owner |
Cape Normandie Shipping Co. Ltd. |
|
Latest data adjustment |
07 March 2017 |
