Westerschelde 11 December 2015 |
 |
 |
|
| Westerschelde 11/12/15 | Westerschelde 11/12/15 | |
|
Name |
MEDALTA ADVENTURER |
|
Type |
Chemical tanker |
|
IMO-number |
9761451 |
|
Call sign |
ZGFB4 |
|
Flag |
Cayman Islands |
|
Port of registry |
George Town |
|
GT |
21.117 t registered |
|
DWT |
Summer: 30.727 t Winter: 29.839 t |
|
NT |
7.540 t registered Suez: 18.449,32 t |
|
Displacement |
Summer: 39.058 t Winter: 38.170 t |
|
Length |
175,00 m overall |
|
Breadth |
27,70 m moulded |
|
Draught |
Summer: 10,01 m Winter: 9,80 m |
|
Moulded L x B x D |
166,70 x 27,70 x 16,00 m |
|
Registered L x B x D |
168,04 x 27,70 x 16,00 m |
|
Air draft |
37,19 m at SDWT condition 42,74 m at full ballast condition |
|
Freeboard |
Summer: 6.013 mm Winter: 6.221 mm |
|
Depth |
16,00 m moulded |
|
Speed |
Service: 14,5 knots Max.: 16,5 knots |
|
Built |
2015 |
|
Keel laid |
22.08.2014 |
|
Launch date |
22.01.2015 |
|
Date of completion |
07.08.2015 |
|
Builder |
Minaminippon Shipbuilding Co., Ltd. Ozai Plant Japan |
|
Yard number |
746 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W-Mitsui 6S50ME-C8 - 2 stroke single acting 6 cylinder 500 x 2.000 mm diesel engine 7.230 kW at 108,0 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works - Japan |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 500 mm |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary vertical boiler - 7,8 bar Evaporation: 13,70 t/h Manufacturer: Alfa Laval Qingdao Ltd. |
|
Generators |
4x Main diesel generatorsets each 770 kW |
|
Number of tank |
15 |
|
Cargo tank capacity 98% |
Liquid: 34.881 m³ |
|
Number of slop tanks |
2 |
|
Number of pumps |
17x Centrifugal pumps |
|
Tank capacities |
Fuel oil: 1.797 m³ Fresh water: 363 m³ |
|
Manager |
MOL Tankship Management (Europe) Ltd. |
|
Operator |
Waterfront Shipping Company Ltd. |
|
Registered owner |
FGL Minuet Panama S.A. |
|
Latest data adjustment |
27 April 2017 |
