Name
|
GUANARTEME
|
|
Type
|
Oil products tanker
|
|
IMO-number
|
9280134
|
|
Call sign
|
ECFV
|
|
Flag
|
Spain - Canary Islands
|
|
Port of registry
|
Santa Cruz De Tenerife
|
|
GT
|
2.815 t
|
|
DWT
|
Summer: 4.222 t
|
|
NT
|
1.183 t
|
|
Length
|
96,61 m overall
|
|
Breadth
|
14,20 m registered
|
|
Draught
|
6,21 m
|
|
Reg. Dimensions L x B x D
|
88,80 x 14,20 x 7,65 m
|
|
Rule Dimensions L x B x D
|
88,76 x 14,20 x 7,65 m
|
|
Freeboard
|
Summer: 1.460 mm
|
|
Depth
|
7,65 m registered
|
|
Speed
|
13,5 knots
|
|
Built
|
2004
|
|
Keel laid
|
23.10.2002
|
|
Launch date
|
01.04.2004
|
|
Date of completion
|
16.06.2004
|
|
Builder
|
RMK Marine Shipyard (MK Marine Gemi Yapim Sanayii ve Deniz Tasimaciligi Isletmesi A.S.)
Tuzla-Istanbul
Turkey
|
|
Yard number
|
55
|
|
Hull material
|
Steel
|
|
Hull type
|
Double hull
|
|
Main engine
|
1x Mak 8M25 - 4 stroke single acting 8 cylinder255 x 400 mm diesel engine 2.400 kW / 3.263 bhp at 750 rpm
Built: 12.2002
Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany
|
|
Propellers
|
1
|
|
Boilers
|
1x Thermal oil Installation FTH - 10,0 kg/cm²
Heating surface: 16,2 m²
2Thermal Oil Installation FTH - 10,0 kg/cm²
Heating surface: 16,2 m²
Built: 09.2002
Builder: Aalborg Boiler Production AB
|
|
Shaft generator
|
1x 594 kVA / 400 Volt
|
|
Generators
|
3x Main diesel generatorsets each 495 kVA - 400 Volt
|
|
Cargo tank capacity
|
4.314 m³
|
|
Tank capacities
|
Fuel oil: 159,6 m³
Fresh water: 89,5 m³
Water ballast: 2.199,5 m³
|
|
Manager
|
Petrogas
Santa Cruz De Tenerife
Canary Islands
|
|
Operator
|
D.M. Petrogas
|
|
Owner
|
Distribuidora Maritima Petrogas
Santa Cruz De Tenerife
Canary Islands
|
|
Latest data adjustment
|
20 July 2017
|
