Westerschelde 18 August 2019 |
 |
 |
 |
 |
 |
||||
| Antwerpen 11/09/18 | Antwerpen 11/09/18 | Antwerpen 11/09/18 | Westerschelde 04/04/17 | Westerschelde 11/07/17 | ||||
|
Name |
STOLT SURF |
|
Type |
Tanker for chemicals & oil products |
|
IMO-number |
9168623 |
|
Classification |
DNV |
|
Call sign |
ZCSR3 |
|
Flag |
Cayman Islands |
|
Port of registry |
George Town |
|
GT |
14.900 t |
|
DWT |
Summer: 22.220 t |
|
NT |
7.228 t |
|
Light ship |
8.045 t |
|
Length |
162,60 m overall 154,10 m between perpendiculars |
|
Breadth |
23,72 m extreme |
|
Draught |
10,11 m |
|
Keel to mast end |
44,00 m |
|
Depth |
13,75 m |
|
Speed |
15,2 knots |
|
Built |
2000 |
|
Keel laid |
05/01/1999 |
|
Launch date |
02/06/2000 |
|
Date of completion |
12/12/2000 |
|
Builder |
Juliana Constructora Gijonesa Gijon Spain |
|
Yard number |
363 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 16 |
|
Main engine |
3x Wärtsilä 8R32LN - 2 stroke 4 stroke 8 cylinder 320 c 350 mm combustion engine 9.735 kW / 13.235 hp at 750 rpm |
|
Propulsion |
Diesel/Electric |
|
Propellers |
1x Fixed pitch propeller Builder: Navalips S.A. Factoria de Santander - Spain |
|
Boilers |
2x Thermal oil heater, exhaust heated AKV 104/4 1x Thermal oil heater, exhaust heated AKV 91.3 2x Thermal oil heater, oil fired KV 6.3/50-So |
|
Generators |
1x Wärtsilä 6R32 LNE main diesel generatorset 2x Wärtsilä 8R32 LNE main diesel generatorsets |
|
Emergency generator |
1x Caterpillar 3306 DITA diesel generatorset 260 kW |
|
Bow thruster |
1x 810 kW |
|
Number of cargo tanks |
40 + 2 slop tanks |
|
Cargo tank capacity |
23.340 m³ |
|
Number of pumps |
40x cargo pumps each 220 m³/h |
|
Tank capacities |
Ballast: 9.794,8 m³ |
|
Crew size |
34 |
|
ISM & commercial manager |
Stolt Tankers B.V. Westerlaan 5 3016 CK Rotterdam The Netherlands |
|
Operator |
STJS -Stolt Tankers Joint Service |
|
Registered owner |
SEA 151 Leasing Co. Limited Care of Stolt Tankers BV Westerlaan 5 3016 CK Rotterdam The Netherlands |
|
Latest data adjustment |
03 August 2024 |
