| Westerschelde 23 June 2017 |
 |
 |
 |
||
| Westerschelde 11/03/17 | Westerschelde 11/03/17 | Antwerpen 27/07/17 | ||
|
Name |
MED BALTIC |
|
Previous names |
2011 - 2011Med Baltic 2011 - 2015 Sea Shark |
|
Type |
Oil / chemical tanker |
|
IMO-number |
9462304 |
|
Call sign |
9HA2670 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
5.651 |
|
DWT |
Summer: 8.280 t |
|
NT |
2.602 |
|
Length |
123,90 m overall 116,27 m between perpendiculars |
|
Breadth |
17,20 m moulded |
|
Draught |
Summer: 7,24 m 4,83 m ballast |
|
Air draft |
28,05 m in ballast 29,38 m loaded condition |
|
Height from keel to mast |
36,62 m |
|
Freeboard |
1.977 mm |
|
Depth |
9,20 m moulded |
|
Speed |
13,2 knots |
|
Built |
2011 |
|
Date of completion |
02/02/2011 |
|
Builder |
Med Yilmaz Tersanesi Karadeniz Eregli Turkey |
|
Yard number |
09 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32C - 4 stroke 8 cylinder 320 x 480 mm combustion engine 4.000 kW / 5.435 hp at 600 rpm Built: 02/10/2007 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
2x CHO S-Man AB 65,00 m² - 10,0 bar 1x CHR S-Man AB 48,00 m² - 10,0 bar |
|
Shaft generator |
1x 1.499 kVA - 1.199 kW |
|
Generators |
3x Main diesel generatorsets each 731 kVA - 585 kW - 842 hp |
|
Emergency generator |
1x Diesel generatorset 188 kVA - 150 kW - 272 hp |
|
Bow thruster |
1x 576,65 bhp / 430 kW |
|
Number of tanks |
12 |
|
Cargo tank capacity 98% |
8.918,01 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
184,63 m³ |
|
Number of segregations |
14x Double valves |
|
Pumps |
12x Centrifugal cargo pumps each 350 m³/h 2 x Centrifugal cargo pumps each 100 m³/h 2x Deepwell ballast pumps each 500 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 66,73 m Distance from stern to centre manifold: 57,18 m Distance between manifolds: 750 mm Distance from ship side to manifold: 2,4 m Distance from deck / tray to manifold: 453 mm |
|
Tank capacities |
Fuel oil: 353,59 m³ Ballast: 3.824,45 m³ |
|
Lifting equipment |
1x Crane - SWL 5,0 t centre |
|
Crew size |
18 |
|
Manager |
Uni-Chartering Turbinevej 10 5500 Middelfart Denmark |
|
Operator |
YMN Tanker Deniz Isletmeciligi A.S. Altunizade Mah. Ord. Prof. Fahrettin Kerim Gökay Cad. Denizciler İş Merkezi, A Blok No:18/1 34662 Üsküdar, Istanbul Turkey |
|
Registered owner |
Sea Tankers 3 Ltd. Valletta Malta |
|
Latest data adjustment |
01 December 2024 |
