Westerschelde 10 August 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Antwerpen 16/08/17 | Antwerpen 15/05/18 | Antwerpen 15/05/18 | Antwerpen 15/05/18 | Antwerpen 15/05/18 | Westerschelde 11/05/18 | |||||
 |
||||||||||
| Westerschelde 05/08/17 |
||||||||||
|
Name |
CHEM VENUS |
|
Previous names |
2004 - 05/2011 Golden Venus |
|
Type |
Oil/chemical tanker |
|
IMO-number |
9324215 |
|
Call sign |
D5NX4 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
Republic of Panama, Panama City - Call sign: HOIX |
|
GT |
11.625 t registered |
|
DWT |
Summer: 19.887 t |
|
NT |
6.120 t registered |
|
Length |
145,53 m overall |
|
Breadth |
23,70 m moulded |
|
Draught |
Summer: 9,71 m |
|
Moulded L x B x D |
137,00 x 23,70 x 13,35 m |
|
Registered L x B x D |
137,92 x 23,70 x 13,35 m |
|
Freeboard |
Summer: 3.664 mm |
|
Depth |
13,35 m moulded |
|
Speed |
Service: 14,6 knots Max.: 16,6 knots |
|
Built |
2004 |
|
Keel laid |
24/06/2004 |
|
Launch date |
05/10/2004 |
|
Date of completion |
09/12/2004 |
|
Builder |
Usuki Shipyard Co., Ltd. Usuki Japan |
|
Yard number |
1693 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x B&W/Kawasaki 6S42MC - 2 stroke single acting 6 cylinder 420 x 1.764 mm combustion engine 6.150 kW / 8.361 hp at 136,0 rpm Manufacturer: Kawasaki Heavy Industries, Ltd., Kobe - japan |
|
Propeller shaft |
1x Sea water lubrication shaft Diameter: 420 mm |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Auxiliary boiler WTB - 9,0 bar Evaporation: 19,00 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
3x Main diesel generatrsets each 575 kVA - 450 Volt |
|
Bow thruster |
1x 550 kW |
|
Number of cargo tanks |
26 |
|
Cargo tank capacity |
Liquid: 22.672 m³ |
|
Tank capacities |
Fuel oil: 1.072 m³ Fresh water: 225 m³ |
|
Manager |
ASM Maritime B.V. WTC, Tower D Strawinskylaan 1057 1077 XX Amsterdam The Netherlands |
|
Operator |
Ace Tankers CV Strawinskylaan 1057 1077 XX Amsterdam The Netherlands |
|
Registered owner |
Chem Venus S.A. |
|
Renamed |
10/2022 G Silver South Korea, Jeju - Call sign: D7GP Owner & manager: Green Bridge Co., Ltd. |
|
Latest data adjustment |
15 May 2023 |
