Westerschelde 07 September 2018 |
 |
 |
|
| Westerschelde 06/08/17 | Westerschelde 15/02/19 | |
|
Name |
MAERSK ELLIOT |
|
Previous names |
2005 - 10/2010 Bro Elliot |
|
Type |
Tanker for chemicals & Oil products |
|
IMO-number |
9274678 |
|
Call sign |
9V3480 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
2009 - 2014 France, Marseille 2014 - 2015 Denmark, Copenhagen - Call sign: OWVB2 |
|
GT |
26.659 t |
|
DWT |
Summer: 36.809 t |
|
NT |
10.206 t |
|
Displacement |
48.241 t |
|
Length |
185,60 m overall 176,00 m between perpendiculars |
|
Breadth |
31,30 m extreme 31,00 m moulded |
|
Draught |
10,60 m |
|
Keel to mast end |
48,42 m |
|
Freeboard |
Summer: 5.900 mm Winter: 6.040 mm |
|
Depth |
16,50 m |
|
Speed |
Service: 15,2 knots Max.: 19,9 knots |
|
Built |
2005 |
|
Keel laid |
19/03/2004 |
|
Date of completion |
02/11/2005 |
|
Builder |
China Chang Jiang National Shipping Group Corporation Jinling Shipyard 55, Yanjiang Road 210015 Nanjing , Jiangsu People's Republic of China |
|
Yard number |
02-0506 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double hull |
|
Main engine |
1x MAN B&W/Hudong Heavy Machinery 6S50MC - 2 stroke 6 cylinder 500 x 1.910 mm combustion engine 8.580 kW / 11.506 bhp at 127,0 rpm Builder: Hudong Zhonghua Shipbuilding Group, Shanghai - China |
|
Propellers |
1x Controllable pitch propeller - aft at 127 rpm |
|
Boilers |
1x Steam boiler, oil fired / exhaust gas heated - 10,0 bar Heating surface: 41,0 m² Heating surface: 391,0 m² 1x Steam boiler, oil fired - 10,0 bar Heating surface: 217 m² Year of manufacture: 2003 Manufacturer: Alfa Laval Qingdao Ltd. 86 Guangzhou Road North Jiaozhou 266300 Qingdao , Shandong People's Republic of China |
|
Electric installations |
1x Plant 450/230 V - 1.237,5 kVA 1x Plant 450/230 V - 1.237,5 kVA 1x Plant 450/230 V - 1.237,5 kVA 1x Plant 450 V - 1.375 kVA 1x Plant 450 V - 287,5 kVA |
|
Shaft generator |
1x 1.375 kVA |
|
Generators |
3x MAN-B&W 8L23/30 diesel generatorsets each 1.237,5 kVA |
|
Emergency generator |
1x MAN D2866LXE diesel generatorset 287,5 kVA |
|
Compressed air receivers |
2x Receivers each 3.500 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar 1x Receiver 2.000 litres - 10,0 bar 1x Receiver 500 litres - 10 bar |
|
Bow thruster |
1x Transverse thruster - 1.000 kW, forward |
|
Number of cargo tanks |
16 |
|
Cargo tank capacity |
Liquid: 45.508 m³ |
|
Number of slop tanks |
2 |
|
Number of pumps |
16x cargo pumps each 500 m³/h |
|
Tank capacities |
Ballast: 18.206,2 m³ |
|
Anchor equipment |
3x Anchors weight each 8.700 kg Length: 632,50 m Diameter: 73 mm |
|
Manager |
Maersk Tankers A/S Esplanaden 50 1098 Copenhagen, K Denmark |
|
Registered owner |
Maersk Tankers A/S Singapore Pte Ltd. |
|
Renamed |
2021 Katsuyama Marshall Islands, Majuro - Call sing: V7A4392 Manager: Katsuyama Shipping Ltd. - Hong Kong Owner: Katsuyama Shipping Ltd. - Hong Kong |
|
Latest data adjustment |
19 September 2017 |
