Antwerpen 26 April 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 09/06/16 | Westerschelde 05/04/19 | Westerschelde 09/12/18 | Westerschelde 24/02/17 | Antwerpen 26/04/19 | Westerschelde 04/03/17 | |||||
 |
 |
|||||||||
| Westerschelde 04/03/17 | Westerschelde 04/03/17 | |||||||||
|
Name |
CHEMICAL MARKETER |
|
Korean name |
케미칼 마케터 |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9304291 |
|
Call sign |
D7EX |
|
Flag |
South Korea |
|
Port of registry |
Jeju |
|
Previous flags |
03/2004 - 06/2009 Republic of Panama, Panama City 06/2009 - 11/2022 Valletta, Malta - Call Sign: 9HA2018 |
|
GT |
8.261 |
|
DWT |
Summer: 14.298 t |
|
NT |
4.735 |
|
Length |
134,16 m overall |
|
Breadth |
20,50 m |
|
Draught |
8,81 m |
|
Moulded L x B x D |
125,00 x 20,50 x 11,60 m |
|
Registered L x B x D |
125,00 x 20,50 x 11,60 m |
|
Keel to mast end |
36,01 m |
|
Freeboard |
Summer: 2.813 mm |
|
Depth |
11,60 m |
|
Speed |
14,9 knots |
|
Built |
2004 |
|
Keel laid |
06/09/2003 |
|
Launch date |
12/01/2004 |
|
Date of completion |
25/03/2004 |
|
Builder |
Asakawa Shipbuilding Co., Ltd. Imabari Japan |
|
Yard number |
535 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W 7S35MC - 2 stroke single acting 7 cylinder 350 x 1.400 mm combustion engine 5.180 kW / 7.043 hp at 173 rpm Manufacturer: Hitachi Zosen Corporation, Osaka Works
|
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 360 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary Boiler WTB - 9,8 bar Heating surface: 184,2 m² 1x Economizer EGE - 12,8 bar Heating surface: 107,4m² Manufacturer: Miura Co., Ltd, Matsuyama - Japan |
|
Generators |
3x Generatorsets total 1.250 kVA / 450 Volt |
|
Bow thruster |
1x 375 kW |
|
Number of cargo tanks |
20 |
|
Cargo tank capacity |
Liquid: 16.596 m³ |
|
Number of pumps |
10x Cargo pumps each 300 m³/h 10x Cargo pumps each 200 m³/h |
|
Tank capacities |
Fuel oil: 740,6 m³ Fresh water: 103 m³ Water ballast: 4.226,6 m³ |
|
Crew size |
23 |
|
ISM & commercial manager |
Ocean Jade Shipping Co., Ltd. Lung-gu, Busan South Korea |
|
Previous manager |
Fleet Management Limited, Hong Kong - China |
|
Registered owner |
Woojin Shipping Co., Ltd., Seoul - South Korea |
|
Previous owner |
Chemical Marketer Shipping Ltd. - Care of Chemship BV - The Netherlands |
|
Latest data adjustment |
29 December 2024 |
