Vlissingen 04 April 2016 |
 |
 |
 |
||
| Vlissingen 04/04/16 | Vlissingen 04/04/16 | Westerschelde 09/08/17 | ||
|
Name |
NAVIG8 AXINITE |
|
Type |
Oil and chemical tanker |
|
IMO-number |
9719771 |
|
Call sign |
V7GX4 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
23.676 t Suez: 24.999,08 t |
|
DWT |
Summer: 37.596 t |
|
NT |
10.250 t Suez: 21.523,1 t |
|
Displacement |
45.596 t |
|
Length |
184,00 m overall |
|
Breadth |
27,40 m |
|
Draft |
11,51 m |
|
Reg. dimensions L x B x D |
177,42 x 27,40 x17,20 m |
|
Rule dimensions L x B x D |
173,47 x 27,40 x17,20 m |
|
Freeboard |
Summer: 5.714 mm |
|
Depth |
17,20 m |
|
Speed |
14,5 knots |
|
Built |
2015 |
|
Keel laid |
29/01/2015 |
|
Launch date |
27/03/2015 |
|
Date of completion |
13/07/2015 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. 100 Bangeojinsunhwan-Doro Dong-Gu Ulsan South Korea |
|
Yard number |
2519 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x HHI/MAN-B&W 6S50ME-B9 - 2 Stroke 6 cylinder 500 x 2.214 mm combustion engine Mcr 7.290 kW at 99,3 rpm Built: 10/2014 Builder: Hyundai Heavy Industries Co., Ltd., Engine & Machinery Division, Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller Manufacturer: HHI Engine & Machinery Div. |
|
Boilers |
1x Auxiliary Water tube boiler - 8,83 kg/cm² Heating surface: 233,0 m² 1x Auxiliary Boiler CPB - Critical pressure boiler - 8,83 kg/cm² Heating surface: 208,6 m² Built: 02/2015 Boiler: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
1x Main diesel generatorset 1.125 kVA / 450 Volt 2x Main diesel generatorsets 1.375 kVA / 450 Volt |
|
Emmergency generator |
1x Generatorset 150 kW |
|
Cargo tank capacity 100% |
Liquid: 42.993,70 m³ |
|
Tank capacities |
Fuel oil: 944,40 m³ Fresh water: 675,30 m³ Ballast: 17.874,30 m³ Lub oil: 92,80 m³ Diesel oil: 338,70 m³ Hydaulic oil: 17,50 m³ |
|
Lifting equipment |
1x Engine room crane - SWL 4,0 t Manufacturer: Oriental Precision Machinery Co., Ltd. 1x Hose handling crane - SWL 10,0 t 1x Provision crane - SWL 4,0 t Manufacturer: Dongnam Marine Crane Co., Ltd. |
|
Manager |
Navig8 Chemical Tankers Inc. |
|
Technical manager |
Navig8 Shipmanagement Pte. Ltd. |
|
Registered owner |
Sea 12 Leasing Co., Ltd. |
|
Renamed |
2022 Hafnia Axinite 04/2022 Marshall Islands, Majuro - Call sign: V7GX4 04/2023 Republic of Singapore, Singapore City - Call sign: 9V8431 Manager: Hafnia, Singapore 117438 - Republic of Singapore Registered owner: Sea 12 Leasing Co. Limited |
|
Latest data adjustment |
30 September 2024 |
