Westerschelde 23 December 2017 |
 |
 |
 |
 |
|||
| Westerschelde 23/12/17 | Westerschelde 17/12/17 | Antwerpen 28/08/18 | Antwerpen 28/08/18 | |||
|
Name |
STI PARK |
|
Type |
Crude oil tanker - Product carrier - Aframax |
|
IMO-number |
9690793 |
|
Call sign |
V7DI3 |
|
Flag |
Marshall Island |
|
Port of registry |
Majuro |
|
GT |
64.705 t registered Suez: 65.881,49 t |
|
DWT |
Summer: 113.073 t |
|
NT |
33.738 t registered Panama: 53.136,23 t Suez: 60.552,42 t |
|
Length |
256,39 m overall 247,20 m between perpendiculars |
|
Breadth |
43,00 m moulded |
|
Freeboard |
7.229 mm |
|
Depth |
22,00 m moulded |
|
Speed |
Max.: 17,1 knots |
|
Built |
2014 |
|
Keel laid |
29/11/2013 |
|
Launch date |
21/06/2014 |
|
Date of completion |
15/09/2014 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. |
|
Yard number |
S705 |
|
Hull material |
High strength steel Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Gas tight: 1 |
|
Main engine |
1x HHI/MAN-B&W6G60ME-C9.2 - 6 cylinder 600 x 2.790 mm diesel engine 11.760 kW / 15.993 bhp at 77,0 rpm Manufacturer: HHI Engine & Machinery Div. |
|
Propellers |
1 Manufacturer: HHI Engine & Machinery Div. |
|
Boilers |
1x Fired boiler - 12,0 bar 1x Fired exhaust gas boiler - 8,0 bar Manufacturer: Alfa Laval Qingdao Ltd. |
|
Generators |
2x Main diesel generatorsets each 900 kW 2x Main diesel generatorsets each 1.250 kW Manufacturer: HHI Electro Electric System |
|
Emergency generator |
1x Diesel generatorset 150 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 100% |
137.796,4 m³ |
|
Number of tanks |
Ballast: 14 Fuel oil: 9 Diesel oil: 7 Lubricating oil: 6 Slop: 3 Sludge: 3 Fresh water: 2 Waste water: 2 Chain: 2 Hydraulic oil: 2 Sea water: 1 |
|
Tank capacities 100% |
Diesel oil: 567,7 m³ / 474,21 t Freshwater: 353,2 m³ Fuel oil: 2.282,6 m³ / 2.236,94 t Hydraulic oil: 41,8 m³ / 36,86 t Lube oil: 149,4 m³ / 131,77 t Tank ballast: 42.580 m³ / 43.644,5 t |
|
Lifting equipment |
1x Engine room overhead crane - SWL 6,3 t 1x Hose handling crane port - SWL 15,0 t 1x Hose Handling crane starboard - SWL 15,0 t 1x Provision crane port - SWL 6,3 t 1x Provision crane starboard - SWL 2,0 t |
|
Manager |
Scorpio tankers Inc. |
|
Operator |
Scorpio Marine Management (India) Pvt. Ltd. |
|
Owner |
STI Park Shipping Company Limited |
|
Latest data adjustment |
16 January 2018 |
